ABYSM Snow V
Model Snow VPart no. 832501EAN 6940533542353
41 specifications
- Noise19 dB
- TypeCooler
- Weight727 g
- ColourBlack, White
- Suitable locationProcessor
- Power consumption (typical)2.4 W
Overview
- Noise
- 19 dB
- Type
- Cooler
- Weight
- 727 g
- Colour
- Black, White
- Suitable location
- Processor
- Power consumption (typical)
- 2.4 W
- Brand
- ABYSM
- Category
- Computer Cooling System
- Model
- Snow V
- Part number
- 832501
- EAN / UPC
- 6940533542353
- Also known as
- ABYSM Snow V Processor Cooler 12 cm Black, White
Specifications
41 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Processor |
| Type | Cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1366 (Socket B), LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, LGA 775 (Socket T), Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2+ |
| Compatible processor series | Not supported |
| Rotational speed (min) | 800 RPM |
| Rotational speed (max) | 1400 RPM |
| Noise level (low speed) | 19 dB |
| Noise level (high speed) | 22.9 dB |
| Minimum airflow (imperial) | 30 cfm |
| Maximum airflow | 60 cfm |
| Maximum air pressure | 1.65 mmH2O |
| Bearing type | Hydraulic |
| Mean time between failures (MTBF) | 30000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black, White |
| Number of fans | 1 fan(s) |
| Number of fan blades | 11 |
| Number of fins | 46 |
| Fins material | Aluminium |
| Number of heat pipes | 5 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 2.4 W |
| Voltage | 12 V |
| Thermal Design Power (TDP) | 180 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 131 mm |
| Depth | 96.5 mm |
| Height | 151 mm |
| Weight | 727 g |
| Fan dimensions (W x D x H) | 120 x 25 x 120 mm |
| Fan weight | 140 g |
| Heatsink weight | 587 g |
| Heat pipes diameter | 6 mm |
| Package width | 175 mm |
| Package depth | 124 mm |
| Package height | 199 mm |
| Package weight | 1 kg |
Packaging content
| Specification | Value |
|---|---|
| Package type | Box |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 540 mm |
| Master (outer) case length | 515 mm |
| Master (outer) case height | 265 mm |
| Master (outer) case gross weight | 13.6 kg |
| Products per master (outer) case | 12 pc(s) |
