Case fan oceanic tide black
120 mm
Model AB311201EAN 8436617921155
27 specifications
- TypeFan
- ColourBlack
- Suitable locationComputer case
- Rated voltage12 V
- Fan dimensions (W x D x H)120 x 120 x 25 mm
- Compliance certificatesCE
Overview
- Type
- Fan
- Colour
- Black
- Suitable location
- Computer case
- Rated voltage
- 12 V
- Fan dimensions (W x D x H)
- 120 x 120 x 25 mm
- Compliance certificates
- CE
- Brand
- ABYSM
- Category
- Computer Cooling System
- Model
- AB311201
- Part number
- AB311201
- EAN / UPC
- 8436617921155
- Also known as
- ABYSM Case fan oceanic tide black 120 mm
Specifications
27 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Suitable location | Computer case |
| Type | Fan |
| Fan diameter | 12 cm |
| Maximum airflow | 76.6 cfm |
| Maximum air pressure | 1.97 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Fan noise level (max) | 35.4 dB |
| Quantity per pack | 1 pc(s) |
| Fan speed (max) | 1800 RPM |
| Fan speed (min) | 800 RPM |
| Fan's mean time to failure (MTTF) | 50000 h |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Number of fan blades | 9 |
| Fan connector | 4-pin |
Power
| Specification | Value |
|---|---|
| Rated voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Fan weight | 160 g |
| Cable length | 0.5 m |
| Package width | 140 mm |
| Package depth | 123 mm |
| Package height | 27 mm |
| Package weight | 300 g |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE |
Packaging content
| Specification | Value |
|---|---|
| Package type | Box |
Other features
| Specification | Value |
|---|---|
| Cooling capacity in watts (max) | 3.36 W |
