K1 Rev.A
Model K1 Rev.APart no. K1.REV.AEAN 823884209150
54 specifications
- TypeMidi Tower
- Weight6.4 kg
- ColourBlack
- Power supply locationBottom
- USB 2.0 ports quantity2
- Front fans installed1x 120 mm
Overview
- Type
- Midi Tower
- Weight
- 6.4 kg
- Colour
- Black
- Power supply location
- Bottom
- USB 2.0 ports quantity
- 2
- Front fans installed
- 1x 120 mm
- Brand
- Zalman
- Category
- Computer Case
- Model
- K1 Rev.A
- Part numbers
- K1.REV.A, K1 REV.A
- EAN / UPC
- 823884209150, 8809213769481, 8809213769269
- Also known as
- Zalman K1 Rev.A Midi Tower Black
Specifications
54 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Form factor | Midi Tower |
| Type | PC |
| Material | Plastic, Steel |
| Product colour | Black |
| Supported motherboard form factors | ATX, micro ATX, Mini-ITX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 2 |
| Number of expansion slots | 7 |
| Side window | Yes |
| Suitable for | Gaming |
| Illumination | Yes |
| Illumination colour | Blue, Green, Red |
| Illumination location | Case fans, Front |
| Tempered glass panel(s) | Yes |
| Anti-dust filter | Yes |
| Built-in speaker(s) | No |
| Cable management | Yes |
| On/off button | Yes |
| Reset button | Yes |
| LED indicators | HDD, Power |
| Maximum CPU cooler height | 17.8 cm |
| Maximum graphics card length | 38 cm |
| Maximum PSU length | 19 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply location | Bottom |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Front fans installed | 1x 120 mm |
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120,140 mm |
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120,140 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120,140 mm |
| Number of bottom fans supported (max) | 2 |
| Bottom fans diameters supported | 120 mm |
| Liquid cooling capability | Yes |
| Front radiator sizes supported | 120,240,280,360 mm |
| Rear radiator sizes supported | 120 mm |
| Top radiator sizes supported | 120,240 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
| HDD/SSD combo cage | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 458 mm |
| Depth | 210 mm |
| Height | 450 mm |
| Weight | 6.4 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 310 mm |
| Package depth | 520 mm |
| Package height | 575 mm |
| Package weight | 8 g |
