VCO-A1699P Rev. 2.2
Model VCO-A1699P Rev. 2.2Part no. VCO-A1699P REV. 2.2EAN 8052780306461
34 specifications
- TypeMidi Tower
- ColourBlack
- Power supply includedYes
- USB 2.0 ports quantity2
- Supported HDD sizes2.5,3.5,5.25"
- Compliance certificatesCE, RoHS
Overview
- Type
- Midi Tower
- Colour
- Black
- Power supply included
- Yes
- USB 2.0 ports quantity
- 2
- Supported HDD sizes
- 2.5,3.5,5.25"
- Compliance certificates
- CE, RoHS
- Brand
- Vultech
- Category
- Computer Case
- Model
- VCO-A1699P Rev. 2.2
- Part number
- VCO-A1699P REV. 2.2
- EAN / UPC
- 8052780306461
- Also known as
- Vultech VCO-A1699P Rev. 2.2 Midi Tower Black 250 W
Specifications
34 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Form factor | Midi Tower |
| Type | PC |
| Material | Metal |
| Product colour | Black |
| Supported motherboard form factors | ATX, micro ATX, Mini-ATX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 1 |
| Number of 2.5" bays | 2 |
| On/off button | Yes |
| Reset button | Yes |
| Maximum CPU cooler height | 14.8 cm |
| Maximum graphics card length | 32 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Power supply | 250 W |
| Power supply location | Top |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 2 |
| Front fans diameters supported | 120 mm |
| Number of side fans supported (max) | 2 |
| Side fans diameters supported | 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 80 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5,5.25" |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 175 mm |
| Depth | 365 mm |
| Height | 415 mm |
| Material thickness | 0.5 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 230 mm |
| Package depth | 410 mm |
| Package height | 450 mm |
