UK 4229 EVO
Model UK 4229 EVOPart no. UK51917EAN 6974560220526
39 specifications
- TypeRack
- Weight10.5 kg
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity0
- Number of front fans supported (max)1
Overview
- Type
- Rack
- Weight
- 10.5 kg
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 0
- Number of front fans supported (max)
- 1
- Brand
- UNYKAch
- Category
- Computer Case
- Model
- UK 4229 EVO
- Part number
- UK51917
- EAN / UPC
- 6974560220526
- Also known as
- UNYKAch UK 4229 EVO Rack Black
Specifications
39 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Form factor | Rack |
| Type | Server |
| Material | SGCC |
| Product colour | Black |
| Supported motherboard form factors | ATX |
| Number of 3.5" bays | 7 |
| Number of 5.25" bays | 0 |
| Number of internal 3.5" bays | 6 |
| Number of internal 5.25" bays | 0 |
| Number of external 5.25" bays | 3 |
| Number of expansion slots | 7 |
| Rack mounting | Yes |
| Rack capacity | 4U |
| Side window | No |
| Anti-dust filter | Yes |
| On/off button | Yes |
| Reset button | Yes |
| LED indicators | Yes |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Power supply location | Top |
| Supported power supply form factors | ATX |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 1 |
| Front fans diameters supported | 120 mm |
| Number of rear fans supported (max) | 2 |
| Rear fans diameters supported | 80 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 430 mm |
| Depth | 535 mm |
| Height | 170 mm |
| Weight | 10.5 kg |
| Material thickness | 1 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 560 mm |
| Package depth | 600 mm |
| Package height | 246 mm |
| Package weight | 12.1 kg |
