Exagon EVO RGB
Model Exagon EVO RGBPart no. 511103EAN 6940533543206
55 specifications
- TypeTower
- Weight6.8 kg
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity2
- Front fans installed3x 120 mm
Overview
- Type
- Tower
- Weight
- 6.8 kg
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 2
- Front fans installed
- 3x 120 mm
- Brand
- UNYKAch
- Category
- Computer Case
- Model
- Exagon EVO RGB
- Part number
- 511103
- EAN / UPC
- 6940533543206
- Also known as
- UNYKAch Exagon EVO RGB Tower Black
Specifications
55 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Form factor | Tower |
| Type | PC |
| Material | SPCC, Tempered glass |
| Product colour | Black |
| Supported motherboard form factors | ATX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 1 |
| Number of 2.5" bays | 3 |
| Number of internal 3.5" bays | 2 |
| Number of external 5.25" bays | 1 |
| Number of expansion slots | 7 |
| Side window | Yes |
| Suitable for | Gaming |
| Illumination | Yes |
| Illumination colour | Blue, Green, Red |
| Illumination location | Front |
| Tempered glass panel(s) | Yes |
| Anti-dust filter | Yes |
| On/off button | Yes |
| Reset button | Yes |
| Maximum CPU cooler height | 15.5 cm |
| Maximum graphics card length | 40 cm |
| Certification | CE / ROHS |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Number of power supply units | 1 |
| Power supply location | Bottom |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Front fans installed | 3x 120 mm |
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120 mm |
| Number of bottom fans supported (max) | 2 |
| Bottom fans diameters supported | 120 mm |
| Liquid cooling capability | Yes |
| Front radiator sizes supported | 360 mm |
| Top radiator sizes supported | 240 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 202 mm |
| Depth | 468 mm |
| Height | 454 mm |
| Weight | 6.8 kg |
| Material thickness | 0.6 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 515 mm |
| Package depth | 542 mm |
| Package height | 515 mm |
| Package weight | 8.3 kg |
Other features
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Screws included | Yes |
