UNYKAch Exagon Evo
Model Exagon EvoPart no. 511102EAN 6940533542643
51 specifications
- TypeTower
- Weight6.8 kg
- ColourBlack, Transparent
- Power supply includedNo
- USB 2.0 ports quantity2
- Number of front fans supported (max)3
Overview
- Type
- Tower
- Weight
- 6.8 kg
- Colour
- Black, Transparent
- Power supply included
- No
- USB 2.0 ports quantity
- 2
- Number of front fans supported (max)
- 3
- Brand
- UNYKAch
- Category
- Computer Case
- Model
- Exagon Evo
- Part number
- 511102
- EAN / UPC
- 6940533542643
- Also known as
- UNYKAch Exagon Evo Tower Black, Transparent
Specifications
51 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Form factor | Tower |
| Type | PC |
| Material | SPCC |
| Product colour | Black, Transparent |
| Supported motherboard form factors | ATX |
| Number of 3.5" bays | 3 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 3 |
| Number of internal 3.5" bays | 2 |
| Number of expansion slots | 7 |
| Side window | Yes |
| Suitable for | Gaming |
| Illumination | Yes |
| Illumination colour | Red |
| Illumination location | Case fans |
| Tempered glass panel(s) | Yes |
| Anti-dust filter | Yes |
| Built-in speaker(s) | Yes |
| On/off button | Yes |
| Reset button | Yes |
| Maximum CPU cooler height | 15.5 cm |
| Maximum graphics card length | 40 cm |
| Certification | CE RoHS |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120 mm |
| Number of bottom fans supported (max) | 2 |
| Bottom fans diameters supported | 120 mm |
| Liquid cooling capability | Yes |
| Front radiator sizes supported | 360 mm |
| Top radiator sizes supported | 240 mm |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 202 mm |
| Depth | 468 mm |
| Height | 454 mm |
| Weight | 6.8 kg |
| Material thickness | 0.6 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 260 mm |
| Package depth | 515 mm |
| Package height | 542 mm |
| Package weight | 8.3 kg |
Other features
| Specification | Value |
|---|---|
| Bearing type | Hydraulic |
| Easy to customize | Yes |
