Techly I-CASE MP-P4HX-BLK2
Model I-CASE MP-P4HX-BLK2EAN 8057685305519
31 specifications
- TypeRack
- Weight12.1 kg
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity2
- Front fans installed1x 120 mm
Overview
- Type
- Rack
- Weight
- 12.1 kg
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 2
- Front fans installed
- 1x 120 mm
- Brand
- Techly
- Category
- Computer Case
- Model
- I-CASE MP-P4HX-BLK2
- Part numbers
- I-CASE MP-P4HX-BLK2, 305519
- EAN / UPC
- 8057685305519
- Also known as
- Techly Industrial 4U Rackmount Computer Chassis I-CASE MP-P4HX-BLK2
Specifications
31 specifications in 10 groups
Design
| Specification | Value |
|---|---|
| Form factor | Rack |
| Type | Server |
| Material | Metal |
| Product colour | Black |
| Supported motherboard form factors | ATX |
| Number of 3.5" bays | 9 |
| Number of 5.25" bays | 2 |
| Number of internal 3.5" bays | 8 |
| Rack mounting | Yes |
| Rack capacity | 4U |
| Side window | Yes |
| Built-in speaker(s) | No |
| LED indicators | HDD, Power |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Power supply location | Side |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| Number of front USB ports | 2 |
| Front USB | No |
Cooling
| Specification | Value |
|---|---|
| Front fans installed | 1x 120 mm |
| Front fans diameters supported | 120 mm |
| Rear fans diameters supported | 60 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 3.5" |
Supplier features
| Specification | Value |
|---|---|
| Vendor code | 305519 |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 482 mm |
| Depth | 499 mm |
| Height | 177 mm |
| Weight | 12.1 kg |
Other features
| Specification | Value |
|---|---|
| AC adapter included | No |
