MEG Maestro 900R
Model MEG Maestro 900RPart no. MEG MAESTRO 900REAN 824142455319
38 specifications
- TypeFull Tower
- Weight33 kg
- Supported power supply form factorsATX
- USB 2.0 ports quantity0
- Number of side fans supported (max)6
- Supported HDD sizes2.5,3.5"
Overview
- Type
- Full Tower
- Weight
- 33 kg
- Supported power supply form factors
- ATX
- USB 2.0 ports quantity
- 0
- Number of side fans supported (max)
- 6
- Supported HDD sizes
- 2.5,3.5"
- Brand
- MSI
- Category
- Computer Case
- Model
- MEG Maestro 900R
- Part number
- MEG MAESTRO 900R
- EAN / UPC
- 824142455319, 4711377427630
- Also known as
- MSI MEG Maestro 900R Full Tower
Specifications
38 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Form factor | Full Tower |
| Type | PC |
| Supported motherboard form factors | EATX, ATX, micro ATX, Mini-ITX |
| Number of 3.5" bays | 5 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 9 |
| Number of expansion slots | 11 |
| Side window | Yes |
| Illumination | Yes |
| Illumination colour | Multi |
| Illumination location | Bottom, Case fans |
| On/off button | Yes |
| Maximum CPU cooler height | 17 cm |
| Maximum graphics card length | 44 cm |
| Maximum PSU length | 20 cm |
Power supply
| Specification | Value |
|---|---|
| Supported power supply form factors | ATX |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 4 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of side fans supported (max) | 6 |
| Side fans diameters supported | 120 mm |
| Number of top fans supported (max) | 4 |
| Top fans diameters supported | 120,140,160 mm |
| Number of bottom fans supported (max) | 4 |
| Bottom fans diameters supported | 120,140,160 mm |
| Liquid cooling capability | Yes |
| Top radiator sizes supported | 120,140,240,280,360,420 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
| SSD form factor | 2.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 379 mm |
| Depth | 695 mm |
| Height | 671 mm |
| Weight | 33 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 38 kg |
