PILOT Z23 Lite
Model PILOT Z23 LitePart no. ITOCPZ23LEAN 8056157884088
33 specifications
- TypeMini Tower
- Weight4 kg
- ColourBlack
- Power supply includedYes
- USB 2.0 ports quantity1
- Number of front fans supported (max)2
Overview
- Type
- Mini Tower
- Weight
- 4 kg
- Colour
- Black
- Power supply included
- Yes
- USB 2.0 ports quantity
- 1
- Number of front fans supported (max)
- 2
- Brand
- itek
- Category
- Computer Case
- Model
- PILOT Z23 Lite
- Part number
- ITOCPZ23L
- EAN / UPC
- 8056157884088
- Also known as
- itek PILOT Z23 Lite Mini Tower Black 500 W
Specifications
33 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Form factor | Mini Tower |
| Type | PC |
| Material | Acrylonitrile butadiene styrene (ABS), Metal, SGCC |
| Product colour | Black |
| Supported motherboard form factors | micro ATX, Mini-ITX |
| Number of 3.5" bays | 3 |
| Number of 5.25" bays | 1 |
| Number of 2.5" bays | 3 |
| Number of internal 3.5" bays | 2 |
| Number of expansion slots | 4 |
| Maximum CPU cooler height | 1.4 cm |
| Maximum graphics card length | 14 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Power supply | 500 W |
| Power supply location | Top |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 0 |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 2 |
| Front fans diameters supported | 80,92,120 mm |
| Rear fans installed | 1x 80 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 178 mm |
| Depth | 368 mm |
| Height | 353 mm |
| Weight | 4 kg |
| Material thickness | 0.5 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 209 mm |
| Package depth | 390 mm |
| Package height | 400 mm |
| Package weight | 5 kg |
