PILOT Z15
Model PILOT Z15Part no. ITOCPZ15EAN 8056157883005
26 specifications
- TypeMini Tower
- Weight3.7 kg
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity2
- Front fans installed1x 80 mm
Overview
- Type
- Mini Tower
- Weight
- 3.7 kg
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 2
- Front fans installed
- 1x 80 mm
- Brand
- itek
- Category
- Computer Case
- Model
- PILOT Z15
- Part number
- ITOCPZ15
- EAN / UPC
- 8056157883005
- Also known as
- itek PILOT Z15 Mini Tower Black
Specifications
26 specifications in 6 groups
Design
| Specification | Value |
|---|---|
| Form factor | Mini Tower |
| Type | PC |
| Material | SGCC |
| Product colour | Black |
| Supported motherboard form factors | micro ATX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 1 |
| Number of internal 3.5" bays | 1 |
| Maximum CPU cooler height | 15 cm |
| Maximum graphics card length | 18 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Power supply location | Bottom |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Cooling
| Specification | Value |
|---|---|
| Front fans installed | 1x 80 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 92 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 168 mm |
| Depth | 295 mm |
| Height | 353 mm |
| Weight | 3.7 kg |
| Material thickness | 0.6 mm |
