Hiditec Q3 PSU500
Model Q3 PSU500Part no. CH40Q30010EAN 8436545690161
40 specifications
- TypeMicro Tower
- Weight5 kg
- ColourBlack
- Power supply includedYes
- USB 2.0 ports quantity2
- Number of front fans supported (max)1
Overview
- Type
- Micro Tower
- Weight
- 5 kg
- Colour
- Black
- Power supply included
- Yes
- USB 2.0 ports quantity
- 2
- Number of front fans supported (max)
- 1
- Brand
- Hiditec
- Category
- Computer Case
- Model
- Q3 PSU500
- Part number
- CH40Q30010
- EAN / UPC
- 8436545690161
- Also known as
- Hiditec Q3 PSU500 Micro Tower Black 500 W
Specifications
40 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Form factor | Micro Tower |
| Type | PC |
| Material | Plastic |
| Product colour | Black |
| Supported motherboard form factors | micro ATX |
| Number of 3.5" bays | 1 |
| Number of 5.25" bays | 2 |
| Number of internal 3.5" bays | 4 |
| Number of expansion slots | 4 |
| Side window | No |
| Reset button | Yes |
| LED indicators | Yes |
| Maximum CPU cooler height | 12 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Power supply | 500 W |
| Power supply location | Top |
| ATX power connector (20+4 pin) | Yes |
| Floppy drive power connector | 1 |
| Number of SATA connectors | 2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 1 |
| Front fans diameters supported | 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 80 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
| Card reader integrated | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 362 mm |
| Depth | 173 mm |
| Height | 380 mm |
| Weight | 5 kg |
| Material thickness | 0.55 mm |
Other features
| Specification | Value |
|---|---|
| External drive bays | 2 x 5.25", 1 x 3.5" |
| Internal drive bays | 4 |
| On/off switch | Yes |
| Optional fans | 3 |
| Power LED | Yes |
| Ventilation fan(s) | 2 |
| Power protection features | Over current, Over power, Over voltage |
