NEO PSU
Model NEO PSUPart no. CHA010044EAN 8436545693605
32 specifications
- TypeMidi Tower
- Weight4.21 kg
- ColourBlack
- Power supply includedYes
- USB 2.0 ports quantity2
- Rear fans installed1x 120 mm
Overview
- Type
- Midi Tower
- Weight
- 4.21 kg
- Colour
- Black
- Power supply included
- Yes
- USB 2.0 ports quantity
- 2
- Rear fans installed
- 1x 120 mm
- Brand
- Hiditec
- Category
- Computer Case
- Model
- NEO PSU
- Part number
- CHA010044
- EAN / UPC
- 8436545693605
- Also known as
- Hiditec NEO PSU Midi Tower Black
Specifications
32 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Form factor | Midi Tower |
| Type | PC |
| Material | ABS, SPCC |
| Product colour | Black |
| Supported motherboard form factors | ATX, ITX, micro ATX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 2 |
| Cable management | Yes |
| On/off button | Yes |
| RGB control button | Yes |
| Maximum graphics card length | 31 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | Yes |
| ATX power connector (20+4 pin) | Yes |
| Number of SATA connectors | 3 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 4 |
| Rear fans diameters supported | 120 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Packaging content
| Specification | Value |
|---|---|
| EPS power connector (4+4 pin) | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 183 mm |
| Depth | 430 mm |
| Height | 345 mm |
| Weight | 4.21 kg |
| Material thickness | 0.5 mm |
