H3 PRO
Model H3 PROPart no. CHA010059EAN 8436545694183
42 specifications
- TypeMidi Tower
- Weight6.9 kg
- ColourBlack, Transparent
- Power supply includedNo
- USB 2.0 ports quantity1
- Number of side fans supported (max)3
Overview
- Type
- Midi Tower
- Weight
- 6.9 kg
- Colour
- Black, Transparent
- Power supply included
- No
- USB 2.0 ports quantity
- 1
- Number of side fans supported (max)
- 3
- Brand
- Hiditec
- Category
- Computer Case
- Model
- H3 PRO
- Part numbers
- CHA010059, CHA010060
- EAN / UPC
- 8436545694183, 8436545694190
- Also known as
- Hiditec H3 PRO Midi Tower Black, Transparent
Specifications
42 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Form factor | Midi Tower |
| Type | PC |
| Material | Tempered glass |
| Product colour | Black, Transparent |
| Supported motherboard form factors | ATX, micro ATX, ITX, BTF |
| Number of 3.5" bays | 1 |
| Number of 2.5" bays | 2 |
| Side window | Yes |
| Illumination | Yes |
| Illumination colour | Multi |
| Illumination location | Back |
| Tempered glass panel(s) | Yes |
| Anti-dust filter | Yes |
| On/off button | Yes |
| Maximum CPU cooler height | 16.5 cm |
| Maximum graphics card length | 40 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Supported power supply form factors | ATX |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB Type-C ports quantity | 1 |
| Combo headphone/mic port | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of side fans supported (max) | 3 |
| Side fans diameters supported | 120 mm |
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 3 |
| Top fans diameters supported | 120 mm |
| Number of bottom fans supported (max) | 3 |
| Bottom fans diameters supported | 120 mm |
| Liquid cooling capability | Yes |
| Side radiator sizes supported | 360,280,240 mm |
| Rear radiator sizes supported | 120 mm |
| Top radiator sizes supported | 360,280,240 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 3.5,2.5" |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 291 mm |
| Depth | 436 mm |
| Height | 435 mm |
| Weight | 6.9 kg |
Other features
| Specification | Value |
|---|---|
| Fan connector | 4-pin |
