S110-B Case Mini Tower mITX, mATX Black
Model S110-BPart no. POC0000240EAN 4711498480408
32 specifications
- TypeSmall Form Factor (SFF)
- Weight3.7 kg
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity2
- Rear fans installed1x 120 mm
Overview
- Type
- Small Form Factor (SFF)
- Weight
- 3.7 kg
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 2
- Rear fans installed
- 1x 120 mm
- Brand
- FSP
- Category
- Computer Case
- Model
- S110-B
- Part number
- POC0000240
- EAN / UPC
- 4711498480408, 4711498480477
- Also known as
- FSP S110-B Case Mini Tower mITX, mATX Black
Specifications
32 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Form factor | Small Form Factor (SFF) |
| Type | PC |
| Material | Mesh, Metal |
| Product colour | Black |
| Supported motherboard form factors | micro ATX, Mini-ITX |
| Number of 3.5" bays | 2 |
| Number of 2.5" bays | 1 |
| Number of expansion slots | 4 |
| Maximum CPU cooler height | 16 cm |
| Maximum graphics card length | 28.5 cm |
| Maximum PSU length | 14 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Supported power supply form factors | ATX |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
Cooling
| Specification | Value |
|---|---|
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120 mm |
| Number of bottom fans supported (max) | 2 |
| Bottom fans diameters supported | 120 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 3.5" |
| SSD form factor | 2.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200 mm |
| Depth | 350 mm |
| Height | 382 mm |
| Weight | 3.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 245 mm |
| Package depth | 420 mm |
| Package height | 402 mm |
| Package weight | 4.2 kg |
