Uniface Mini
Model Uniface MiniPart no. 3855C90.0001EAN 4710483777400
48 specifications
- TypeMini Tower
- Weight5.84 kg
- ColourWhite
- Power supply includedNo
- USB 2.0 ports quantity1
- Number of front fans supported (max)3
Overview
- Type
- Mini Tower
- Weight
- 5.84 kg
- Colour
- White
- Power supply included
- No
- USB 2.0 ports quantity
- 1
- Number of front fans supported (max)
- 3
- Brand
- COUGAR
- Category
- Computer Case
- Model
- Uniface Mini
- Part numbers
- 3855C90.0001, 3855C90.0002
- EAN / UPC
- 4710483777400, 192554007533, 4541995038297, 4710483777417 +2 more
- Also known as
- COUGAR Uniface Mini Mini Tower White
Specifications
48 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Form factor | Mini Tower |
| Type | PC |
| Product colour | White |
| Supported motherboard form factors | micro ATX, Mini-ITX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 4 |
| Number of expansion slots | 4 |
| Side window | Yes |
| Suitable for | Gaming |
| Tempered glass panel(s) | Yes |
| Anti-dust filter | Yes |
| On/off button | Yes |
| Reset button | Yes |
| LED indicators | Yes |
| Maximum CPU cooler height | 16 cm |
| Maximum graphics card length | 34 cm |
| Maximum PSU length | 16 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 0 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120,140 mm |
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120,140 mm |
| Fan speed | 1080 - 1320 RPM |
| Liquid cooling capability | Yes |
| Front radiator sizes supported | 120,140,240,280 mm |
| Rear radiator sizes supported | 120 mm |
| Top radiator sizes supported | 120,240 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 390 mm |
| Height | 422 mm |
| Weight | 5.84 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 272 mm |
| Package depth | 480 mm |
| Package height | 480 mm |
| Package weight | 6.69 kg |
Other features
| Specification | Value |
|---|---|
| Fan connector | 3-pin |
