Gemini M
Model Gemini MPart no. 385TMB0.0002EAN 4715302442514
45 specifications
- TypeMini Tower
- Weight5.54 kg
- ColourSilver
- Power supply includedNo
- USB 2.0 ports quantity1
- Number of front fans supported (max)3
Overview
- Type
- Mini Tower
- Weight
- 5.54 kg
- Colour
- Silver
- Power supply included
- No
- USB 2.0 ports quantity
- 1
- Number of front fans supported (max)
- 3
- Brand
- COUGAR
- Category
- Computer Case
- Model
- Gemini M
- Part numbers
- 385TMB0.0002, 385TMB0.0001
- EAN / UPC
- 4715302442514, 4715302442477
- Also known as
- COUGAR Gemini M Mini Tower Silver
Specifications
45 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Form factor | Mini Tower |
| Type | PC |
| Product colour | Silver |
| Supported motherboard form factors | micro ATX, Mini-ITX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 2 |
| Number of expansion slots | 4 |
| Side window | Yes |
| Illumination | Yes |
| Illumination colour | Blue, Green, Red |
| Illumination location | Front |
| Cable management | Yes |
| On/off button | Yes |
| Reset button | Yes |
| Maximum CPU cooler height | 17.5 cm |
| Maximum graphics card length | 33 cm |
| Maximum PSU length | 16 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Supported power supply form factors | ATX, PS2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120,140 mm |
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120,140 mm |
| Liquid cooling capability | Yes |
| Front radiator sizes supported | 120,140,240,280 mm |
| Rear radiator sizes supported | 120 mm |
| Top radiator sizes supported | 120,140,240 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 400 mm |
| Height | 423 mm |
| Weight | 5.54 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 260 mm |
| Package depth | 460 mm |
| Package height | 495 mm |
| Package weight | 6.65 kg |
