PC micro ATX M840
Model PC micro ATX M840Part no. COO-PCM840-0EAN 8436624420207
39 specifications
- TypeMicro Tower
- Weight2.8 kg
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity2
- Number of front fans supported (max)1
Overview
- Type
- Micro Tower
- Weight
- 2.8 kg
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 2
- Number of front fans supported (max)
- 1
- Brand
- CoolBox
- Category
- Computer Case
- Model
- PC micro ATX M840
- Part number
- COO-PCM840-0
- EAN / UPC
- 8436624420207
- Also known as
- CoolBox PC micro ATX M840 Micro Tower Black
Specifications
39 specifications in 6 groups
Design
| Specification | Value |
|---|---|
| Form factor | Micro Tower |
| Type | PC |
| Material | SPCC |
| Product colour | Black |
| Supported motherboard form factors | micro ATX, Mini-ITX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 1 |
| Number of internal 3.5" bays | 2 |
| Number of storage drives supported | 3 |
| Number of expansion slots | 4 |
| Suitable for | Home/Office |
| On/off button | Yes |
| Reset button | Yes |
| LED indicators | Yes |
| Maximum CPU cooler height | 14 cm |
| Maximum graphics card length | 26.5 cm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Power supply location | Top |
| Supported power supply form factors | ATX |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 0 |
| Combo headphone/mic port | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 1 |
| Front fans diameters supported | 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 80 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
| HDD/SSD combo cage | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 165 mm |
| Depth | 295 mm |
| Height | 354 mm |
| Weight | 2.8 kg |
| Material thickness | 0.8 mm |
