BX-10B-M-OP computer case Mini Tower Black
Model BX-10B-M-OPEAN 753263078414
39 specifications
- TypeMini Tower
- ColourBlack
- Power supply includedNo
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
- Rear fans installed1x 120 mm
- Supported HDD sizes2.5,3.5"
Overview
- Type
- Mini Tower
- Colour
- Black
- Power supply included
- No
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 1
- Rear fans installed
- 1x 120 mm
- Supported HDD sizes
- 2.5,3.5"
- Brand
- Chieftec
- Category
- Computer Case
- Model
- BX-10B-M-OP
- Part number
- BX-10B-M-OP
- EAN / UPC
- 753263078414
- Also known as
- Chieftec BX-10B-M-OP computer case Mini Tower Black
Specifications
39 specifications in 7 groups
Design
| Specification | Value |
|---|---|
| Form factor | Mini Tower |
| Type | PC |
| Material | Metal |
| Product colour | Black |
| Supported motherboard form factors | micro ATX, Mini-ITX |
| Number of 3.5" bays | 1 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 3 |
| Number of internal 3.5" bays | 1 |
| Number of expansion slots | 4 |
| Side window | No |
| Illumination | No |
| Cable management | Yes |
| On/off button | Yes |
| Maximum CPU cooler height | 16.5 cm |
| Maximum graphics card length | 38 cm |
| Maximum PSU length | 18 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Power supply location | Rear |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Audio input | Yes |
| Audio output | Yes |
| USB Type-C ports quantity | 1 |
| Combo headphone/mic port | Yes |
Cooling
| Specification | Value |
|---|---|
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120,140 mm |
| Number of bottom fans supported (max) | 3 |
| Bottom fans diameters supported | 120,140 mm |
| Top radiator sizes supported | 240 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
| SSD form factor | 2.5" |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 2 year(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 204 mm |
| Depth | 415 mm |
| Height | 325 mm |
| Material thickness | 0.6 mm |
