Chieftec BT-04B-U3 computer case Mini Tower Black
250 W
Model BT-04B-U3
32 specifications
- TypeMini Tower
- Weight3.5 kg
- ColourBlack
- Power supply includedYes
- USB 2.0 ports quantity0
- Number of front fans supported (max)1
Overview
- Type
- Mini Tower
- Weight
- 3.5 kg
- Colour
- Black
- Power supply included
- Yes
- USB 2.0 ports quantity
- 0
- Number of front fans supported (max)
- 1
- Brand
- Chieftec
- Category
- Computer Case
- Model
- BT-04B-U3
- Part number
- BT-04B-U3
- Also known as
- Chieftec BT-04B-U3 computer case Mini Tower Black 250 W
Specifications
32 specifications in 6 groups
Design
| Specification | Value |
|---|---|
| Form factor | Mini Tower |
| Type | PC |
| Material | SECC |
| Product colour | Black |
| Supported motherboard form factors | Mini-ITX |
| Number of 3.5" bays | 1 |
| Number of 5.25" bays | 1 |
| Number of 2.5" bays | 2 |
| Number of external 5.25" bays | 1 |
| Number of expansion slots | 2 |
| Side window | No |
| Suitable for | Home/Office |
| Built-in speaker(s) | No |
| Maximum CPU cooler height | 7 cm |
| Maximum graphics card length | 20 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Power supply | 250 W |
| Power supply location | Bottom |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 1 |
| Front fans diameters supported | 80 mm |
| Number of rear fans supported (max) | 2 |
| Rear fans diameters supported | 60 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 135 mm |
| Depth | 240 mm |
| Height | 323 mm |
| Weight | 3.5 kg |
| Material thickness | 0.6 mm |
