AL-02B-TG-OP computer case Tower Black
Model AL-02B-TG-OPEAN 753263076717
37 specifications
- TypeTower
- Weight5.85 kg
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity1
- Number of front fans supported (max)3
Overview
- Type
- Tower
- Weight
- 5.85 kg
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 1
- Number of front fans supported (max)
- 3
- Brand
- Chieftec
- Category
- Computer Case
- Model
- AL-02B-TG-OP
- Part number
- AL-02B-TG-OP
- EAN / UPC
- 753263076717, 7532630767174
- Also known as
- Chieftec AL-02B-TG-OP computer case Tower Black
Specifications
37 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Form factor | Tower |
| Type | PC |
| Material | Aluminium, SPCC, Tempered glass |
| Product colour | Black |
| Supported motherboard form factors | ATX, micro ATX, Mini-ITX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 1 |
| Number of external 5.25" bays | 1 |
| Number of expansion slots | 7 |
| Side window | Yes |
| Tempered glass panel(s) | Yes |
| Anti-dust filter | Yes |
| Cable management | Yes |
| On/off button | Yes |
| Reset button | Yes |
| Maximum CPU cooler height | 16.6 cm |
| Maximum graphics card length | 34.9 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Supported power supply form factors | ATX |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120,240 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200 mm |
| Depth | 435 mm |
| Height | 450 mm |
| Weight | 5.85 kg |
| Material thickness | 0.6 mm |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 6.85 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
Other features
| Specification | Value |
|---|---|
| Screws included | Yes |
