Pure Base 500DX
Model Pure Base 500DXPart no. BGW37EAN 4260052188446
52 specifications
- TypeMidi Tower
- Weight7.8 kg
- ColourBlack
- Power supply includedNo
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
- Front fans installed1x 140 mm
Overview
- Type
- Midi Tower
- Weight
- 7.8 kg
- Colour
- Black
- Power supply included
- No
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 1
- Front fans installed
- 1x 140 mm
- Brand
- be quiet!
- Category
- Computer Case
- Model
- Pure Base 500DX
- Part numbers
- BGW37, BGW38, BGW42
- EAN / UPC
- 4260052188446, 4260052187937, 4260052187944
- Also known as
- be quiet! Pure Base 500DX Black
Specifications
52 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Form factor | Midi Tower |
| Type | PC |
| Material | Acrylonitrile butadiene styrene (ABS), Steel, Tempered glass |
| Product colour | Black |
| Supported motherboard form factors | ATX, micro ATX, Mini-ATX |
| Number of 3.5" bays | 2 |
| Number of 2.5" bays | 5 |
| Number of expansion slots | 7 |
| Side window | Yes |
| Illumination | Yes |
| Illumination colour | Blue, Green, Red |
| Illumination location | Front, Internal |
| Tempered glass panel(s) | Yes |
| Anti-dust filter | Yes |
| On/off button | Yes |
| Maximum CPU cooler height | 19 cm |
| Maximum graphics card length | 36.9 cm |
| Maximum PSU length | 25.8 cm |
| Certification | CE, RoHS |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Power supply location | Bottom |
| Supported power supply form factors | ATX, PS2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Front fans installed | 1x 140 mm |
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120,140 mm |
| Front fans supported description | 140x140x25 mm, 900 rpm, 17.1 dB , 55.8 cfm |
| Rear fans installed | 1x 140 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120,140 mm |
| Rear fans supported description | 140x140x25 mm, 900 rpm, 17.1 dB , 55.8 cfm |
| Top fans installed | 1x 140 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120,140 mm |
| Top fans supported description | 140x140x25 mm, 900 rpm, 17.1 dB , 55.8 cfm |
| Front radiator sizes supported | 120,140,240,280,360 mm |
| Rear radiator sizes supported | 120,140 mm |
| Top radiator sizes supported | 120,140 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 232 mm |
| Depth | 450 mm |
| Height | 443 mm |
| Weight | 7.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 285 mm |
| Package depth | 510 mm |
| Package height | 494 mm |
| Package weight | 8.49 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
