TUF Gaming GT502 Horizon
Model TUF Gaming GT502 HorizonPart no. 90DC0090-B08020EAN 197105652736
35 specifications
- TypeMidi Tower
- Weight11 kg
- ColourWhite
- Power supply includedNo
- USB 2.0 ports quantity0
- Number of rear fans supported (max)1
Overview
- Type
- Midi Tower
- Weight
- 11 kg
- Colour
- White
- Power supply included
- No
- USB 2.0 ports quantity
- 0
- Number of rear fans supported (max)
- 1
- Brand
- ASUS
- Category
- Computer Case
- Model
- TUF Gaming GT502 Horizon
- Part numbers
- 90DC0090-B08020, 90DC0093-B08020, 90DC0090-B00020
- EAN / UPC
- 197105652736, 197105652743, 4711387652725, 197105652712 +1 more
- Also known as
- ASUS TUF Gaming GT502 Horizon Midi Tower White
Specifications
35 specifications in 6 groups
Design
| Specification | Value |
|---|---|
| Form factor | Midi Tower |
| Type | PC |
| Product colour | White |
| Supported motherboard form factors | ATX, micro ATX, Mini-ITX |
| Number of 3.5" bays | 4 |
| Number of expansion slots | 8 |
| Side window | Yes |
| Tempered glass panel(s) | Yes |
| Anti-dust filter | Yes |
| On/off button | Yes |
| RGB control button | Yes |
| Reset button | Yes |
| Maximum CPU cooler height | 16.3 cm |
| Maximum graphics card length | 40 cm |
| Maximum PSU length | 20 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| USB Type-C ports quantity | 1 |
| Combo headphone/mic port | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 3 |
| Top fans diameters supported | 120,140 mm |
| Liquid cooling capability | Yes |
| Rear radiator sizes supported | 120 mm |
| Top radiator sizes supported | 120,140,240,280,360 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 285 mm |
| Depth | 450 mm |
| Height | 446 mm |
| Weight | 11 kg |
