PRIME AP303 MESH WHITE
Model PRIME AP303 MESH WHITEPart no. 90DC00V3-B30000EAN 199291165090
32 specifications
- TypeMidi Tower
- Weight6.8 kg
- ColourWhite
- USB 2.0 ports quantity0
- Rear fans installed1x 120 mm
- Supported HDD sizes2.5,3.5"
Overview
- Type
- Midi Tower
- Weight
- 6.8 kg
- Colour
- White
- USB 2.0 ports quantity
- 0
- Rear fans installed
- 1x 120 mm
- Supported HDD sizes
- 2.5,3.5"
- Brand
- ASUS
- Category
- Computer Case
- Model
- PRIME AP303 MESH WHITE
- Part number
- 90DC00V3-B30000
- EAN / UPC
- 199291165090, 4711636165099
- Also known as
- ASUS PRIME AP303 MESH WHITE Midi Tower
Specifications
32 specifications in 5 groups
Design
| Specification | Value |
|---|---|
| Form factor | Midi Tower |
| Type | PC |
| Product colour | White |
| Supported motherboard form factors | ATX, micro ATX, Mini-ITX |
| Number of 3.5" bays | 1 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 2 |
| Number of expansion slots | 7 |
| Suitable for | Gaming |
| Anti-dust filter | Yes |
| Cable management | Yes |
| Maximum CPU cooler height | 16.5 cm |
| Maximum graphics card length | 36 cm |
| Maximum PSU length | 18 cm |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Combo headphone/mic port | Yes |
Cooling
| Specification | Value |
|---|---|
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 3 |
| Top fans diameters supported | 120,140 mm |
| Rear radiator sizes supported | 120 mm |
| Top radiator sizes supported | 120,140,240,280,360 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 215 mm |
| Depth | 485 mm |
| Height | 425 mm |
| Weight | 6.8 kg |
