Trinity Mini
Model Trinity MiniPart no. TRINITYMINIWHV3EAN 4711099470761
33 specifications
- TypeMini Tower
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity1
- Front fans installed2x 140 mm
- Supported HDD sizes2.5,3.5"
Overview
- Type
- Mini Tower
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 1
- Front fans installed
- 2x 140 mm
- Supported HDD sizes
- 2.5,3.5"
- Brand
- Aerocool
- Category
- Computer Case
- Model
- Trinity Mini
- Part numbers
- TRINITYMINIWHV3, TRINITYMINIBKV2, ACCS-PV32133.11, TRINITYMINIPKV3
- EAN / UPC
- 4711099470761, 4710562758627, 4710562758634, 4711099470792
- Also known as
- Aerocool Trinity Mini Mini Tower Black
Specifications
33 specifications in 6 groups
Design
| Specification | Value |
|---|---|
| Form factor | Mini Tower |
| Type | PC |
| Material | ABS, SPCC |
| Product colour | Black |
| Supported motherboard form factors | micro ATX, Mini-ITX |
| Number of 3.5" bays | 2 |
| Number of 2.5" bays | 3 |
| Number of expansion slots | 4 |
| Illumination | Yes |
| Cable management | Yes |
| Maximum CPU cooler height | 15.8 cm |
| Maximum graphics card length | 29.7 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Supported power supply form factors | ATX |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Front fans installed | 2x 140 mm |
| Number of front fans supported (max) | 2 |
| Front fans diameters supported | 120,140 mm |
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120 mm |
| Front radiator sizes supported | 120,240 mm |
| Rear radiator sizes supported | 120 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 206.5 mm |
| Depth | 353.4 mm |
| Height | 385 mm |
| Material thickness | 0.5 mm |
