Bolt Mini
Model Bolt MiniPart no. BOLTMINIBKEAN 4710562750034
45 specifications
- TypeMini Tower
- Weight2.81 kg
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity2
- Supported HDD sizes2.5,3.5"
Overview
- Type
- Mini Tower
- Weight
- 2.81 kg
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 2
- Supported HDD sizes
- 2.5,3.5"
- Brand
- Aerocool
- Category
- Computer Case
- Model
- Bolt Mini
- Part number
- BOLTMINIBK
- EAN / UPC
- 4710562750034, 4710562750041
- Also known as
- Aerocool Bolt Mini Mini Tower Black
Specifications
45 specifications in 8 groups
Design
| Specification | Value |
|---|---|
| Form factor | Mini Tower |
| Type | PC |
| Material | ABS synthetics, Acrylic, SPCC |
| Product colour | Black |
| Supported motherboard form factors | micro ATX, Mini-ATX |
| Number of 3.5" bays | 2 |
| Number of 5.25" bays | 0 |
| Number of 2.5" bays | 4 |
| Number of expansion slots | 4 |
| Side window | Yes |
| Suitable for | Gaming |
| Illumination | Yes |
| Illumination colour | Multi |
| Illumination location | Front |
| On/off button | Yes |
| Reset button | Yes |
| LED indicators | Status |
| Maximum CPU cooler height | 15.8 cm |
| Maximum graphics card length | 31.8 cm |
| Maximum PSU length | 18.6 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Power supply location | Bottom |
| Supported power supply form factors | ATX |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Audio input | Yes |
| Audio output | Yes |
Cooling
| Specification | Value |
|---|---|
| Number of front fans supported (max) | 2 |
| Front fans diameters supported | 120 mm |
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120 mm |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200.7 mm |
| Depth | 381.1 mm |
| Height | 369.5 mm |
| Weight | 2.81 kg |
| Material thickness | 0.5 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 422 mm |
| Package depth | 232 mm |
| Package height | 435 mm |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733080 |
