Arian Frame A400
Model Arian Frame A400Part no. AB123533EAN 8436617921506
60 specifications
- TypePC
- Weight8.18 kg
- ColourBlack
- Power supply includedNo
- USB 2.0 ports quantity0
- Fan speed controlYes
Overview
- Type
- PC
- Weight
- 8.18 kg
- Colour
- Black
- Power supply included
- No
- USB 2.0 ports quantity
- 0
- Fan speed control
- Yes
- Brand
- ABYSM
- Category
- Computer Case
- Model
- Arian Frame A400
- Part number
- AB123533
- EAN / UPC
- 8436617921506
- Also known as
- ABYSM Gaming ATX Arian Frame A400 Black
Specifications
60 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Type | PC |
| Material | SPCC |
| Product colour | Black |
| Supported motherboard form factors | ATX, ITX, micro ATX |
| Number of 3.5" bays | 1 |
| Number of 2.5" bays | 1 |
| Number of internal 3.5" bays | 1 |
| Number of expansion slots | 7 |
| Side window | Yes |
| Suitable for | Gaming |
| Illumination | Yes |
| Illumination colour | Multi |
| Illumination location | Case fans |
| Tempered glass panel(s) | Yes |
| Anti-dust filter | Yes |
| Cable management | Yes |
| On/off button | Yes |
| Maximum CPU cooler height | 18.2 cm |
| Maximum graphics card length | 42 cm |
Power supply
| Specification | Value |
|---|---|
| Power supply included | No |
| Power supply location | Bottom |
| Supported power supply form factors | ATX |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 0 |
| Combo headphone/mic port | Yes |
Cooling
| Specification | Value |
|---|---|
| Fan speed control | Yes |
| Side fans installed | 3x 120 mm |
| Number of side fans supported (max) | 3 |
| Side fans diameters supported | 120 mm |
| Rear fans installed | 1x 120 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120,140 mm |
| Number of top fans supported (max) | 3 |
| Top fans diameters supported | 120,140 mm |
| Number of bottom fans supported (max) | 1 |
| Bottom fans diameters supported | 120 mm |
| Fan 2 maximum air pressure | 1.1 mmH2O |
| Fan 2 maximum airflow | 40.7 cfm |
| Fan speed | 600 - 1600 RPM |
| Maximum air pressure | 1.1 mmH2O |
| Maximum airflow | 39.6 cfm |
| Liquid cooling capability | Yes |
| Top radiator sizes supported | 240,280,360 mm |
| Pulse-width modulation (PWM) support | Yes |
Storage
| Specification | Value |
|---|---|
| Supported HDD sizes | 2.5,3.5" |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 3 year(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 235 mm |
| Depth | 483 mm |
| Height | 446 mm |
| Weight | 8.18 kg |
| Material thickness | 0.7 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 295 mm |
| Package depth | 520 mm |
| Package height | 555 mm |
| Package weight | 9.52 kg |
Other features
| Specification | Value |
|---|---|
| Bearing type | Hydraulic |
| Mean time between failures (MTBF) | 30000 h |
