Product comparison · 2 wireless routers

Intellinet 524490 wireless router Fast Ethernet Grey vs Intellinet 524780 wireless router Fast Ethernet Grey

Add a product
  • 53specifications compared
  • 15differ
  • 38identical
  • 34known for one product only

Key differences

  • VPN support
    • PPTP, IPSec, L2TP
    • PPTP
  • LED indicators
    • LAN, Power, WLAN, Yes
    • LAN, Status, Yes
  • Certification
    • FCC - B, CE, RoHS
    • FCC Class B, CE Mark, RoHS
  • Processor model
    • Ralink RT3052
    • Realtek RTL8192SU
  • Flash memory
    • 4 MB
    • 2 MB
  • Power consumption (typical)
    • 2.7 W
    • 12 W
  • Storage temperature (T-T)
    • -20 - 60 °C
    • 0 - 60 °C
  • Dimensions (WxDxH)
    • 157 x 127 x 30 mm
    • 187 x 100 x 30 mm

Side by side

Differences highlightedShow differences only
87 specifications
A

Intellinet

524490 wireless router Fast Ethernet Grey

Model 524490

View product
B

Intellinet

524780 wireless router Fast Ethernet Grey

Model 524780

View product
WAN connectionidentical
Ethernet WANKnown for oneYes
DSL WANKnown for oneYes
Wireless LAN featuresidentical
WLAN data transfer rate (max)Known for one300 Mbit/s
Channels quantity14 channels14 channels
Top Wi-Fi standardKnown for oneWi-Fi 4 (802.11n)
Wi-Fi standardsKnown for one802.11b, 802.11g, Wi-Fi 4 (802.11n)
Network1 differ
Ethernet LANYesYes
Ethernet LAN interface typeFast EthernetFast Ethernet
Ethernet LAN data rates10,100 Mbit/s10,100 Mbit/s
Cabling technologyKnown for one10/100BASE-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3uIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Full duplexYesYes
VPN supportDiffersPPTP, IPSec, L2TPPPTP
Receiver sensitivityKnown for one11n (300 Mbps) MCS0-15: - 20 MHz: -73 dBm; - 40MHz: -68 dBm 11g (54 Mbps) OFDM: -78 dBm 11b (11 Mbps) CCK: -91 dBm
Supports ISDN connectionKnown for oneNo
Ports & interfacesidentical
Ethernet LAN (RJ-45) ports44
DC-in jackYesYes
RJ-11 ports quantityKnown for one1
Management featuresidentical
Web-based managementYesYes
Quality of Service (QoS) supportYesYes
Security1 differ
Security algorithmsDiffers128-bit WEP, 256-bit WEP, WPA, WPA2128-bit WEP, 64-bit WEP, WPA, WPA-AES
DoS attack preventionKnown for oneYes
FilteringYesYes
MAC address filteringYesYes
URL filteringYesYes
System event logYesYes
NAT functionalityYesYes
DMZ supportKnown for oneYes
Network address translation (NAT)Known for oneYes
Protocolsidentical
DHCP clientYesYes
DHCP serverYesYes
Universal Plug and Play (UPnP)YesYes
Supported network protocolsKnown for oneCSMA/CA, CSMA/CD, TCP/IP, UDP, ICMP, PPPoE, NTP, NAT, DHCP, DNS
Management protocolsKnown for oneSNMP
Design1 differ
Product colourGreyGrey
Indication lightYesYes
LED indicatorsDiffersLAN, Power, WLAN, YesLAN, Status, Yes
Packaging contentidentical
Cables includedLAN (RJ-45)LAN (RJ-45)
AC adapter includedYesYes
ManualKnown for oneYes
Quick start guideKnown for oneYes
Certificates1 differ
CertificationDiffersFCC - B, CE, RoHSFCC Class B, CE Mark, RoHS
Antennaidentical
Antenna gain level (max)3 dBi3 dBi
Antennas quantity22
Features2 differ
Built-in processorYesYes
Processor modelDiffersRalink RT3052Realtek RTL8192SU
Internal memory16 MB16 MB
Flash memoryDiffers4 MB2 MB
Plug and PlayYesYes
Firmware upgradeableYesYes
Power1 differ
Power consumption (typical)Differs2.7 W12 W
Power over Ethernet (PoE)NoNo
Operational conditions1 differ
Operating relative humidity (H-H)10 - 90%10 - 90%
Operating temperature (T-T)0 - 40 °C0 - 40 °C
Storage temperature (T-T)Differs-20 - 60 °C0 - 60 °C
Weight & dimensionsidentical
Weight800 g800 g
Other features7 differ
Cable length1 m1 m
CompatibilityKnown for oneIEEE 802.1d IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.3 IEEE 802.3u
Compliance industry standardsKnown for oneIEEE 802.3/802.3u, IEEE 802.11b/g/n
Dimensions (WxDxH)Differs157 x 127 x 30 mm187 x 100 x 30 mm
Frequency range2.400 - 2.4835 GHz2.400 - 2.4835 GHz
Indoor rangeKnown for one100 m
Input frequencyDiffers50 Hz50/60 Hz
Input voltageDiffers5 V100 - 240 V
Networking featuresKnown for oneFast Ethernet
Operating temperature (T-T)Known for one32 - 122 °F
Outdoor rangeKnown for one300 m
Ports quantityKnown for one4
Power requirementsDiffers5 V DC, 1.0 A12 V DC, 1 A
Power supply typeAC/DCAC/DC
Rack mountingNoNo
Security featuresDiffersMAC, URL, DMZ, anti-DOSVPN PPTP, L2TP, IPsec
Supported protocolsKnown for oneCSMA/CA, CSMA/CD, TCP/IP, UDP, ICMP, PPPoE, NTP, NAT, DHCP, DNS
ThroughputKnown for one93 Mb/s
USB ports quantityKnown for one0
WLAN data transfer rates supportedDiffers300 Mbit/s24 Mbit/s
xDSL connectionDiffersNoYes
Dimensions (W x D x H) (imperial)Known for one193 x 127 x 35.6 mm (7.6 x 5 x 1.4")
LAN featuresAuto MDI/MDI-XAuto MDI/MDI-X
Logging and monitoringYesYes
Downstream data rateKnown for one24 Mbit/s
InterfaceKnown for oneFE
Memory and processorKnown for oneYes
Supported WAN typeKnown for oneADSL
Upstream data rateKnown for one1 Mbit/s
DSL featuresidentical
ADSLKnown for oneYes
DSL specificationKnown for oneITU G.992.5, ITU G.992.4, ITU G.992.3, ITU G.992.2, ITU G.992.1, ANSI T1.413

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
