Product comparison · 2 video signal converters

StarTech.com Micro HDMI or HDMI to VGA Adapter vs StarTech.com Composite and S-Video to HDMI Converter with Audio

24specifications compared
16differ
8identical
12known for one product only

Key differences

Maximum video resolution
- Micro HDMI or HDMI to VGA Adapter:1920 x 1200 pixels
- Composite and S-Video to HDMI Converter with Audio:1600 x 1200 pixels
Host interface
- Micro HDMI or HDMI to VGA Adapter:HDMI
- Composite and S-Video to HDMI Converter with Audio:Composite, S-Video
Output interface
- Micro HDMI or HDMI to VGA Adapter:VGA
- Composite and S-Video to HDMI Converter with Audio:HDMI
Operating current
- Micro HDMI or HDMI to VGA Adapter:1 A
- Composite and S-Video to HDMI Converter with Audio:1.2 A
Power consumption (typical)
- Micro HDMI or HDMI to VGA Adapter:1.75 W
- Composite and S-Video to HDMI Converter with Audio:2.5 W
Operating temperature (T-T)
- Micro HDMI or HDMI to VGA Adapter:0 - 45 °C
- Composite and S-Video to HDMI Converter with Audio:0 - 40 °C
Storage temperature (T-T)
- Micro HDMI or HDMI to VGA Adapter:-20 - 70 °C
- Composite and S-Video to HDMI Converter with Audio:-20 - 60 °C
Width
- Micro HDMI or HDMI to VGA Adapter:41 mm
- Composite and S-Video to HDMI Converter with Audio:163 mm

Side by side

Differences highlightedShow differences only

Comparison of MCHD2VGA, VID2HDCON
36 specifications	A StarTech.com Micro HDMI or HDMI to VGA Adapter Model MCHD2VGA View product	B StarTech.com Composite and S-Video to HDMI Converter with Audio Model VID2HDCON View product
Featuresidentical
Converter type	Active video converter	Active video converter
Product colour	Black	Black
Housing material	Plastic	Plastic
Certification	CE, FCC, REACH	CE, FCC, REACH
Video2 differ
Maximum video resolutionDiffers	1920 x 1200 pixels	1600 x 1200 pixels
Video resolutionsDiffers	1600 x 1200,1920 x 1080,1920 x 1200	1024 x 768,1280 x 1024,1600 x 1200
Analog signal format systemKnown for one	Unknown — not stated by the source	NTSC, PAL
Supported video modesKnown for one	1080p, 480p, 720p	Unknown — not stated by the source
Maximum refresh rateKnown for one	60 Hz	Unknown — not stated by the source
Ports & interfaces2 differ
Host interfaceDiffers	HDMI	Composite, S-Video
Output interfaceDiffers	VGA	HDMI
3.5 mm connectorKnown for one	Unknown — not stated by the source	Yes
Power2 differ
External power adapter	Yes	Yes
Input currentKnown for one	Unknown — not stated by the source	0.3 A
Input voltage	100 - 240 V	100 - 240 V
Operating currentDiffers	1 A	1.2 A
Operating voltage	5 V	5 V
Power consumption (typical)Differs	1.75 W	2.5 W
Power plug typeKnown for one	Unknown — not stated by the source	Type M
USB poweredKnown for one	Yes	Unknown — not stated by the source
Technical detailsidentical
Compliance certificates	RoHS	RoHS
Operational conditions2 differ
Operating temperature (T-T)Differs	0 - 45 °C	0 - 40 °C
Storage temperature (T-T)Differs	-20 - 70 °C	-20 - 60 °C
Operating relative humidity (H-H)Known for one	Unknown — not stated by the source	20 - 90%
Weight & dimensions4 differ
WidthDiffers	41 mm	163 mm
DepthDiffers	64 mm	164 mm
HeightDiffers	14 mm	34 mm
WeightDiffers	38 g	79 g
Packaging data4 differ
Included power plug typesKnown for one	Unknown — not stated by the source	ANZ, EU, JP, NA, UK
Package widthDiffers	150 mm	155 mm
Package depthDiffers	210 mm	124 mm
Package heightDiffers	50 mm	56 mm
Package weightDiffers	284 g	310 g
Cables includedKnown for one	HDMI	Unknown — not stated by the source
AC adapter includedKnown for one	Yes	Unknown — not stated by the source
Logistics dataidentical
Harmonized System (HS) codeKnown for one	Unknown — not stated by the source	85176990

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
