FSP Champ Rack 6KL
FSP

Champ Rack 6KL

Model Champ Rack 6KLPart no. PPF54A1301EAN 4713224524844

40 specifications
  • Noise50 dB
  • TypeRackmount/Tower
  • Weight15 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • USB portYes
See all specifications

Overview

Noise
50 dB
Type
Rackmount/Tower
Weight
15 kg
Colour
Black
UPS topology
Double-conversion (Online)
USB port
Yes
Brand
FSP
Model
Champ Rack 6KL
Part number
PPF54A1301
EAN / UPC
4713224524844
Also known as
FSP Champ Rack 6KL uninterruptible power supply (UPS) Double-conversion (Online) 6 kVA 5400 W

Specifications

40 specifications in 10 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity6 kVA
Output power5400 W
WaveformSine
Input operation voltage (min)110 V
Input operation voltage (max)300 V
Input frequency46/64 Hz
Output operation voltage (min)208 V
Output operation voltage (max)240 V
Output frequency46/64 Hz
Output voltage regulation1%
Power factor0.9
Crest factor3:1
Emergency Power Off (EPO)Yes
Total Harmonic Distortion (THD) (linear load)3%
Total Harmonic Distortion (THD) (non-linear load)5%
Noise level50 dB

Ports & interfaces

USB portYes
USB 2.0 ports quantity1
USB port typeUSB Type-B
Serial interfaceYes
Serial interface typeRS-232
Emergency Power Off (EPO) connectorYes

Battery

Number of batteries supported20

Design

Form factorRackmount/Tower
Product colourBlack
Control typeButtons
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 95%

Packaging content

Cables includedInput power cable, USB cable
ManualYes

Certificates

Compliance certificatesCE

Weight & dimensions

Width530 mm
Depth438 mm
Height88 mm
Weight15 kg

Logistics data

Harmonized System (HS) code85078000

Other features

Packaging contentUPS, user manual, software CD, USB cable, cable for battery pack
