Product comparison · 2 servers

ASUS TS100 E9-M58 vs ASUS TS100 E9-M62

56specifications compared
6differ
50identical
50known for one product only

Key differences

Processor model
- TS100 E9-M58:E3-1220 v6
- TS100 E9-M62:E3-1220V6
Optical drive type
- TS100 E9-M58:DVD Super Multi DL
- TS100 E9-M62:DVD-RW
Serial ports quantity
- TS100 E9-M58:2
- TS100 E9-M62:1
VGA (D-Sub) ports quantity
- TS100 E9-M58:2
- TS100 E9-M62:1
Width
- TS100 E9-M58:423 mm
- TS100 E9-M62:190 mm
Depth
- TS100 E9-M58:190 mm
- TS100 E9-M62:423 mm

Side by side

Differences highlightedShow differences only

Comparison of TS100 E9-M58, TS100 E9-M62
106 specifications	A ASUS TS100 E9-M58 View product	B ASUS TS100 E9-M62 View product
Processor1 differ
Processor manufacturerKnown for one	Intel	Unknown — not stated by the source
Processor family	Intel® Xeon® E3 v6	Intel® Xeon® E3 v6
Processor modelDiffers	E3-1220 v6	E3-1220V6
Processor frequency	3 GHz	3 GHz
Processor boost frequency	3.5 GHz	3.5 GHz
Processor cores	4	4
Processor cache	8 MB	8 MB
Motherboard chipset	Intel® C232	Intel® C232
Memory channels supported by processorKnown for one	Dual	Unknown — not stated by the source
Number of processors installed	1	1
Thermal Design Power (TDP)Known for one	72 W	Unknown — not stated by the source
Processor cache type	Smart Cache	Smart Cache
System bus rate	8 GT/s	8 GT/s
Bus typeKnown for one	DMI3	Unknown — not stated by the source
ECC supported by processorKnown for one	Yes	Unknown — not stated by the source
Embedded options availableKnown for one	No	Unknown — not stated by the source
Execute Disable BitKnown for one	Yes	Unknown — not stated by the source
Idle StatesKnown for one	Yes	Unknown — not stated by the source
Maximum internal memory supported by processorKnown for one	64 GB	Unknown — not stated by the source
Maximum number of PCI Express lanesKnown for one	16	Unknown — not stated by the source
Memory bandwidth supported by processor (max)Known for one	37.5 GB/s	Unknown — not stated by the source
Memory clock speeds supported by processorKnown for one	1866,2133 MHz	Unknown — not stated by the source
Memory types supported by processorKnown for one	DDR3L, DDR4-SDRAM	Unknown — not stated by the source
PCI Express configurationsKnown for one	1x16, 1x8+2x4, 2x8	Unknown — not stated by the source
Processor codenameKnown for one	Kaby Lake	Unknown — not stated by the source
Processor lithography	14 nm	14 nm
Processor operating modesKnown for one	64-bit	Unknown — not stated by the source
Processor package sizeKnown for one	37.5 x 37.5 mm	Unknown — not stated by the source
Processor socket	LGA 1151 (Socket H4)	LGA 1151 (Socket H4)
Processor threads	4	4
ScalabilityKnown for one	1S	Unknown — not stated by the source
Supported instruction setsKnown for one	AVX 2.0, SSE4.1, SSE4.2	Unknown — not stated by the source
Thermal Monitoring TechnologiesKnown for one	Yes	Unknown — not stated by the source
Conflict-Free processorKnown for one	Yes	Unknown — not stated by the source
Memoryidentical
Internal memory	8 GB	8 GB
Internal memory type	DDR4-SDRAM	DDR4-SDRAM
Memory clock speed	2400 MHz	2400 MHz
Memory layout (slots x size)	1 x 8 GB	1 x 8 GB
Memory slots	4	4
Maximum internal memory	64 GB	64 GB
Storage1 differ
Total storage capacity	1 TB	1 TB
Number of HDDs installed	1	1
HDD capacity	1 TB	1 TB
HDD interface	Serial ATA III	Serial ATA III
HDD speed	7200 RPM	7200 RPM
HDD size	3.5"	3.5"
RAID support	Yes	Yes
RAID levels	0, 1, 5, 10	0, 1, 5, 10
Optical drive typeDiffers	DVD Super Multi DL	DVD-RW
Graphicsidentical
Discrete graphics card	Yes	Yes
Discrete graphics card model	Aspeed AST1400	Aspeed AST1400
Networkidentical
Cabling technology	10/100/1000Base-T(X)	10/100/1000Base-T(X)
Ethernet LAN	Yes	Yes
Ethernet interface type	Gigabit Ethernet	Gigabit Ethernet
LAN controller	Intel® I210-AT	Intel® I210-AT
Ports & interfaces2 differ
Ethernet LAN (RJ-45) ports	2	2
USB 2.0 ports quantity	4	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4	4
PS/2 ports quantity	1	1
Serial ports quantityDiffers	2	1
VGA (D-Sub) ports quantityDiffers	2	1
Number of SATA III connectorsKnown for one	Unknown — not stated by the source	6
Expansion slotsidentical
PCI Express x8 (Gen 3.x) slots	1	1
PCI Express x16 (Gen 3.x) slots	1	1
PCI Express slots versionKnown for one	3.0	Unknown — not stated by the source
PCI slots	4	4
Designidentical
Chassis type	Tower	Tower
Product colour	Black	Black
Softwareidentical
Compatible operating systems	Windows Server 2016 Windows Server 2012 R2 Windows Server 2012 RedHat Enterprise Linux SuSE Linux Enterprise Server CentOS VMware Citrix XenServer	Windows Server 2016 Windows Server 2012 R2 Windows Server 2012 RedHat Enterprise Linux SuSE Linux Enterprise Server CentOS VMware Citrix XenServer
Operating system installedKnown for one	Unknown — not stated by the source	FreeDOS
Processor special featuresidentical
CPU configuration (max)Known for one	1	Unknown — not stated by the source
Enhanced Intel SpeedStep TechnologyKnown for one	Yes	Unknown — not stated by the source
Intel 64Known for one	Yes	Unknown — not stated by the source
Intel Clear Video TechnologyKnown for one	No	Unknown — not stated by the source
Intel Enhanced Halt StateKnown for one	Yes	Unknown — not stated by the source
Intel Secure Key Technology versionKnown for one	1.00	Unknown — not stated by the source
Intel Software Guard Extensions (Intel SGX)Known for one	Yes	Unknown — not stated by the source
Intel TSX-NIKnown for one	Yes	Unknown — not stated by the source
Intel TSX-NI versionKnown for one	1.00	Unknown — not stated by the source
Intel Trusted Execution TechnologyKnown for one	Yes	Unknown — not stated by the source
Intel VT-x with Extended Page Tables (EPT)Known for one	Yes	Unknown — not stated by the source
Intel Virtualization Technology (VT-x)Known for one	Yes	Unknown — not stated by the source
Intel Virtualization Technology for Directed I/O (VT-d)Known for one	Yes	Unknown — not stated by the source
Intel® AES New Instructions (Intel® AES-NI)Known for one	Yes	Unknown — not stated by the source
Intel® Clear Video HD Technology (Intel® CVT HD)Known for one	No	Unknown — not stated by the source
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Known for one	No	Unknown — not stated by the source
Intel® Hyper Threading Technology (Intel® HT Technology)Known for one	No	Unknown — not stated by the source
Intel® InTru™ 3D TechnologyKnown for one	No	Unknown — not stated by the source
Intel® OS GuardKnown for one	Yes	Unknown — not stated by the source
Intel® Quick Sync Video TechnologyKnown for one	No	Unknown — not stated by the source
Intel® Secure KeyKnown for one	Yes	Unknown — not stated by the source
Intel® Turbo Boost TechnologyKnown for one	2.0	Unknown — not stated by the source
Processor ARK IDKnown for one	97470	Unknown — not stated by the source
Poweridentical
Power supply	300 W	300 W
Power supply input frequency	50 - 60 Hz	50 - 60 Hz
Operational conditionsidentical
Operating temperature (T-T)	10 - 35 °C	10 - 35 °C
Storage temperature (T-T)	-40 - 70 °C	-40 - 70 °C
Operating relative humidity (H-H)Known for one	20 - 90%	Unknown — not stated by the source
Storage relative humidity (H-H)Known for one	Unknown — not stated by the source	20 - 90%
Certificatesidentical
Certification	BSMI, CE, C-Tick, FCC(Class B)	BSMI, CE, C-Tick, FCC(Class B)
Logistics dataidentical
Harmonized System (HS) codeKnown for one	84714100	Unknown — not stated by the source
Weight & dimensions2 differ
WidthDiffers	423 mm	190 mm
DepthDiffers	190 mm	423 mm
Height	435 mm	435 mm
Weight	10.3 kg	10.3 kg
Package weight	14.9 kg	14.9 kg

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
