Product comparison · 2 network antennas

Zyxel EXT 106 vs Zyxel Ext 109

Key differences

Differences highlightedShow differences only

Comparison of EXT 106, Ext 109
21 specifications	A Zyxel EXT 106 View product	B Zyxel Ext 109 View product
Performance1 differ
Antenna gain level (max)Differs	6 dBi	9 dBi
Frequency band	2.4 - 2.5 GHz	2.4 - 2.5 GHz
Impedance	50 Ω	50 Ω
Horizontal beam widthKnown for one	Unknown — not stated by the source	65°
Vertical beam widthKnown for one	Unknown — not stated by the source	60°
Features1 differ
Antenna type	Directional antenna	Directional antenna
Antenna connector typeDiffers	RP-SMA	N-type
Connector genderKnown for one	Male	Unknown — not stated by the source
Polarization	Vertical polarization	Vertical polarization
Voltage Standing Wave Ratio (VSWR)Known for one	1.5	Unknown — not stated by the source
Cable lengthKnown for one	1.5 m	Unknown — not stated by the source
MountingKnown for one	Wall	Unknown — not stated by the source
PurposeKnown for one	Indoor	Unknown — not stated by the source
Product colourKnown for one	Unknown — not stated by the source	White
Power handlingKnown for one	Unknown — not stated by the source	20 W
Operational conditions1 differ
Operating temperature (T-T)Differs	-10 - 55 °C	-40 - 80 °C
Operating relative humidity (H-H)Known for one	Unknown — not stated by the source	0 - 95%
Weight & dimensions4 differ
WidthDiffers	118 mm	114 mm
DepthDiffers	86 mm	114 mm
HeightDiffers	76 mm	40 mm
WeightDiffers	110 g	107 g

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
