Product comparison · 2 nas & storage servers

NETGEAR ReadyNas RR2304 vs NETGEAR RR230400-100NES NAS Rack (1U)

74specifications compared
4differ
70identical
6known for one product only

Key differences

Total installed storage capacity
- ReadyNas RR2304:4 TB
- RR230400-100NES NAS Rack (1U):12000 TB
Storage drive capacity
- ReadyNas RR2304:1 TB
- RR230400-100NES NAS Rack (1U):3 TB
AC input voltage
- ReadyNas RR2304:100-240 V
- RR230400-100NES NAS Rack (1U):100 - 240 V

Side by side

Differences highlightedShow differences only

Comparison of ReadyNas RR2304, RR230400-100NES
80 specifications	A NETGEAR ReadyNas RR2304 View product	B NETGEAR RR230400-100NES NAS Rack (1U) Model RR230400-100NES View product
Storage2 differ
Storage drives installed	Yes	Yes
Total installed storage capacityDiffers	4 TB	12000 TB
Number of storage drives installed	4	4
Number of storage drives supported	4	4
Installed storage drive type	HDD	HDD
Supported storage drive types	HDD & SSD	HDD & SSD
Storage drive capacityDiffers	1 TB	3 TB
Storage drive interface	Serial ATA III	Serial ATA III
Storage drive sizes supported	2.5,3.5"	2.5,3.5"
Maximum supported storage capacityKnown for one	48 TB	Unknown — not stated by the source
RAID support	Yes	Yes
RAID levels	0, 1, 5, 6, 10, JBOD	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, ext3, ext4	BTRFS, FAT32, HFS+, NTFS, ext3, ext4
Bad block scan	Yes	Yes
Processoridentical
Processor familyKnown for one	Intel® Celeron®	Unknown — not stated by the source
Processor frequency	2 GHz	2 GHz
Processor coresKnown for one	2	Unknown — not stated by the source
Memoryidentical
Internal memory	2 GB	2 GB
Flash memoryKnown for one	Unknown — not stated by the source	128 MB
Networkidentical
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Wi-Fi	No	No
DHCP client	Yes	Yes
Jumbo frames support	Yes	Yes
iSCSI support	Yes	Yes
Wake-on-LAN ready	Yes	Yes
Dynamic IP	Yes	Yes
Link aggregation	Yes	Yes
Load balancing system	Yes	Yes
Static IP	Yes	Yes
Supported network protocols	TCP/IP, IPv4, IPv6, NTP	TCP/IP, IPv4, IPv6, NTP
Ports & interfacesidentical
Ethernet LAN (RJ-45) ports	2	2
USB port	Yes	Yes
USB 2.0 ports quantity	0	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3	3
Fiber ports quantity	0	0
Designidentical
Chassis type	Rack (1U)	Rack (1U)
Cooling type	Active	Active
Product colour	Black, Grey	Black, Grey
Number of fans	3 fan(s)	3 fan(s)
Fan diameter	4 cm	4 cm
LED indicators	Activity, HDD, LAN, Power	Activity, HDD, LAN, Power
Performance1 differ
Type	NAS	NAS
Device class	Small & Medium Business	Small & Medium Business
Backup function	Yes	Yes
Backup features	Cloud	Cloud
Multilingual support	Yes	Yes
Number of users	40 user(s)	40 user(s)
Management protocols	SNMP v2, v3	SNMP v2, v3
Web-based management	Yes	Yes
Access Control List (ACL)	Yes	Yes
Browser supportedDiffers	Microsoft Internet Exploer 9+, Mozilla Firefox 14+, Google Chrome 20+, Apple Safari 5+	Microsoft Internet Explorer 9+, Mozilla Firefox 14+, Google Chrome 20+, Apple Safari 5+
Built-in UPnP AV media server	Yes	Yes
Hot spare	Yes	Yes
On/off switch	Yes	Yes
S.M.A.R.T. support	Yes	Yes
Security algorithms	256-bit AES, SSH	256-bit AES, SSH
System log	Yes	Yes
Universal Plug and Play (UPnP)	Yes	Yes
Built-in iTunes serverKnown for one	Unknown — not stated by the source	Yes
Softwareidentical
Operating system installedKnown for one	ReadyNAS OS	Unknown — not stated by the source
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1	Windows 10, Windows 7, Windows 8, Windows 8.1
Linux operating systems supported	Yes	Yes
Mac operating systems supported	Yes	Yes
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012	Windows Server 2008 R2, Windows Server 2012
Other operating systems supported	Android, VMware vSphere ESXi, iOS	Android, VMware vSphere ESXi, iOS
Power1 differ
Power supply location	Built-in	Built-in
Power supply unit (PSU) capacity	180 W	180 W
Number of power supply units	1	1
AC input voltageDiffers	100-240 V	100 - 240 V
AC input frequency	50 - 60 Hz	50 - 60 Hz
Weight & dimensionsidentical
Width	430 mm	430 mm
Depth	308 mm	308 mm
Height	44 mm	44 mm
Operational conditionsidentical
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%	5 - 95%
Other featuresidentical
Compliance certificates	RoHS	RoHS
Digital Living Network Alliance (DLNA) certified	Yes	Yes
Certification	FCC B, CE B, VCCI B	FCC B, CE B, VCCI B

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
