Product comparison · 2 all-in-one pcs/workstations

Viewsonic VSD242 Rockchip RK3288 vs Viewsonic VSD242 Smart Display

61specifications compared
9differ
52identical
18known for one product only

Key differences

Display diagonal
- VSD242 Rockchip RK3288:61 cm (24")
- VSD242 Smart Display:59.9 cm (23.6")
Panel type
- VSD242 Rockchip RK3288:IPS
- VSD242 Smart Display:TFT
Wall mountable
- VSD242 Rockchip RK3288:Yes
- VSD242 Smart Display:No
Product type
- VSD242 Rockchip RK3288:All-in-One PC
- VSD242 Smart Display:All-in-One thin client
Weight (with stand)
- VSD242 Rockchip RK3288:5.6 kg
- VSD242 Smart Display:5.64 kg
Package width
- VSD242 Rockchip RK3288:628 mm
- VSD242 Smart Display:643 mm
Package depth
- VSD242 Rockchip RK3288:125 mm
- VSD242 Smart Display:140 mm
Package height
- VSD242 Rockchip RK3288:395 mm
- VSD242 Smart Display:435 mm

Side by side

Differences highlightedShow differences only

Comparison of VSD242, VSD242 Smart Display
79 specifications	A Viewsonic VSD242 Rockchip RK3288 Model VSD242 View product	B Viewsonic VSD242 Smart Display View product
Display2 differ
Display diagonalDiffers	61 cm (24")	59.9 cm (23.6")
Display resolution	1920 x 1080 pixels	1920 x 1080 pixels
Touchscreen	Yes	Yes
HD type	Full HD	Full HD
LED backlightKnown for one	Yes	Unknown — not stated by the source
Touch technology	Multi-touch	Multi-touch
Native aspect ratio	16:9	16:9
Display brightness	250 cd/m²	250 cd/m²
Panel typeDiffers	IPS	TFT
Screen shape	Flat	Flat
Tilt angle rangeKnown for one	0 - 90°	Unknown — not stated by the source
Response timeKnown for one	Unknown — not stated by the source	16 ms
Processoridentical
Processor manufacturer	Rockchip	Rockchip
Processor family	Rockchip	Rockchip
Processor model	RK3288	RK3288
Processor cores	4	4
Processor frequency	1.8 GHz	1.8 GHz
Memoryidentical
Internal memory	2 GB	2 GB
Internal memory type	DDR3-SDRAM	DDR3-SDRAM
Storageidentical
Total storage capacity	16 GB	16 GB
Storage media	Flash	Flash
Optical drive type	No	No
Card reader integrated	Yes	Yes
Compatible memory cards	SD	SD
Graphicsidentical
Discrete graphics card modelKnown for one	Not available	Unknown — not stated by the source
Audioidentical
Built-in speaker(s)	Yes	Yes
RMS rated power	5 W	5 W
Cameraidentical
Built-in camera	Yes	Yes
Total megapixels	5 MP	5 MP
Networkidentical
Wi-Fi	Yes	Yes
Top Wi-Fi standard	Wi-Fi 4 (802.11n)	Wi-Fi 4 (802.11n)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	Yes	Yes
Bluetooth	Yes	Yes
Bluetooth version	4.0	4.0
Ethernet LAN data ratesKnown for one	Unknown — not stated by the source	10,100,1000 Mbit/s
Ports & interfacesidentical
Ethernet LAN (RJ-45) ports	1	1
USB 2.0 ports quantity	5	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0	0
Thunderbolt 3 ports quantity	0	0
Thunderbolt ports quantity	0	0
HDMI ports quantity	2	2
VGA (D-Sub) ports quantity	0	0
Headphone outputs	1	1
Microphone in	Yes	Yes
Audio outputKnown for one	Yes	Unknown — not stated by the source
DC-in jack	Yes	Yes
Design1 differ
Product colour	Black	Black
Wall mountableDiffers	Yes	No
Performance1 differ
Product typeDiffers	All-in-One PC	All-in-One thin client
AccelerometerKnown for one	Unknown — not stated by the source	No
Softwareidentical
Operating system installed	Android 5.1	Android 5.1
Poweridentical
AC adapter powerKnown for one	48 W	Unknown — not stated by the source
AC adapter input voltage	100 - 240 V	100 - 240 V
AC adapter output voltageKnown for one	12 V	Unknown — not stated by the source
AC adapter frequencyKnown for one	Unknown — not stated by the source	50/60 Hz
Weight & dimensions5 differ
Width (with stand)	572.9 mm	572.9 mm
Depth (with stand)	47 mm	47 mm
Height (with stand)	351.8 mm	351.8 mm
Weight (with stand)Differs	5.6 kg	5.64 kg
Package widthDiffers	628 mm	643 mm
Package depthDiffers	125 mm	140 mm
Package heightDiffers	395 mm	435 mm
Package weightDiffers	7.2 kg	7.56 kg
Operational conditionsidentical
Operating temperature (T-T)	0 - 35 °C	0 - 35 °C
Operating relative humidity (H-H)	20 - 90%	20 - 90%
Certificatesidentical
Compliance certificates	RoHS	RoHS
CertificationKnown for one	CE, CB, cTUVus, FCC-B (including ICES003, CA IC, NOM, China CCC, CEL Gost-R, FAC, WEEE, RoHS, REACH, ErP, Argentina CNC, AR-S	Unknown — not stated by the source
Other featuresidentical
AC adapter output currentKnown for one	4 A	Unknown — not stated by the source
Detachable displayKnown for one	No	Unknown — not stated by the source
eMMC capacity	16 GB	16 GB
Autonomy modeKnown for one	Unknown — not stated by the source	No
Packaging contentidentical
Mouse includedKnown for one	Unknown — not stated by the source	No
Keyboard includedKnown for one	Unknown — not stated by the source	No
Power cord includedKnown for one	Unknown — not stated by the source	Yes
Quick start guideKnown for one	Unknown — not stated by the source	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
