Product comparison · 2 all-in-one pcs/workstations

Viewsonic VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3 vs Viewsonic VSD242 Smart Display

62specifications compared
26differ
36identical
22known for one product only

Key differences

Display diagonal
- VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3:58.4 cm (23")
- VSD242 Smart Display:59.9 cm (23.6")
Display brightness
- VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3:300 cd/m²
- VSD242 Smart Display:250 cd/m²
Panel type
- VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3:IPS
- VSD242 Smart Display:TFT
Response time
- VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3:5 ms
- VSD242 Smart Display:16 ms
Processor manufacturer
- VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3:NVIDIA
- VSD242 Smart Display:Rockchip
Processor family
- VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3:NVIDIA Tegra
- VSD242 Smart Display:Rockchip
Processor model
- VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3:Tegra 3
- VSD242 Smart Display:RK3288
Processor frequency
- VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3:1.6 GHz
- VSD242 Smart Display:1.8 GHz

Side by side

Differences highlightedShow differences only

Comparison of VSD231, VSD242 Smart Display
84 specifications	A Viewsonic VSD231 All-in-One PC/workstation NVIDIA Tegra Tegra 3 Model VSD231 View product	B Viewsonic VSD242 Smart Display View product
Display4 differ
Display diagonalDiffers	58.4 cm (23")	59.9 cm (23.6")
Display resolution	1920 x 1080 pixels	1920 x 1080 pixels
Touchscreen	Yes	Yes
HD type	Full HD	Full HD
LED backlightKnown for one	Yes	Unknown — not stated by the source
Touch technology	Multi-touch	Multi-touch
Native aspect ratio	16:9	16:9
Display brightnessDiffers	300 cd/m²	250 cd/m²
Panel typeDiffers	IPS	TFT
Response timeDiffers	5 ms	16 ms
Screen shape	Flat	Flat
Tilt angle rangeKnown for one	0 - 90°	Unknown — not stated by the source
Processor4 differ
Processor manufacturerDiffers	NVIDIA	Rockchip
Processor familyDiffers	NVIDIA Tegra	Rockchip
Processor modelDiffers	Tegra 3	RK3288
Processor cores	4	4
Processor frequencyDiffers	1.6 GHz	1.8 GHz
Memoryidentical
Internal memory	2 GB	2 GB
Internal memory type	DDR3-SDRAM	DDR3-SDRAM
Storage1 differ
Total storage capacityDiffers	8 GB	16 GB
Card reader integrated	Yes	Yes
Compatible memory cards	SD	SD
Storage mediaKnown for one	Unknown — not stated by the source	Flash
Optical drive typeKnown for one	Unknown — not stated by the source	No
Graphicsidentical
Discrete graphics card modelKnown for one	Not available	Unknown — not stated by the source
Audio1 differ
Built-in speaker(s)	Yes	Yes
RMS rated powerDiffers	2 W	5 W
Built-in microphoneKnown for one	Yes	Unknown — not stated by the source
Camera1 differ
Built-in camera	Yes	Yes
Total megapixelsDiffers	2 MP	5 MP
Networkidentical
Wi-Fi	Yes	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Bluetooth	Yes	Yes
Bluetooth version	4.0	4.0
Top Wi-Fi standardKnown for one	Unknown — not stated by the source	Wi-Fi 4 (802.11n)
Ports & interfaces4 differ
Ethernet LAN (RJ-45) ports	1	1
USB 2.0 ports quantityDiffers	2	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantityDiffers	3	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0	0
Thunderbolt 3 ports quantity	0	0
Thunderbolt ports quantity	0	0
HDMI ports quantityDiffers	1	2
VGA (D-Sub) ports quantity	0	0
Headphone outputs	1	1
Microphone inDiffers	No	Yes
DC-in jackKnown for one	Unknown — not stated by the source	Yes
Design1 differ
Product colour	Black	Black
Cable lock slotKnown for one	Yes	Unknown — not stated by the source
Cable lock slot typeKnown for one	Kensington	Unknown — not stated by the source
Wall mountableDiffers	Yes	No
Performance1 differ
Product typeDiffers	All-in-One PC	All-in-One thin client
AccelerometerKnown for one	Unknown — not stated by the source	No
Software1 differ
Operating system installedDiffers	Android 4.3	Android 5.1
Poweridentical
AC adapter powerKnown for one	48 W	Unknown — not stated by the source
AC adapter frequencyKnown for one	Unknown — not stated by the source	50/60 Hz
AC adapter input voltageKnown for one	Unknown — not stated by the source	100 - 240 V
Weight & dimensions8 differ
Width (with stand)Differs	547.1 mm	572.9 mm
Depth (with stand)Differs	192.4 mm	47 mm
Height (with stand)Differs	392.6 mm	351.8 mm
Weight (with stand)Differs	7.2 kg	5.64 kg
Width (without stand)Known for one	547.1 mm	Unknown — not stated by the source
Depth (without stand)Known for one	48.3 mm	Unknown — not stated by the source
Height (without stand)Known for one	370.8 mm	Unknown — not stated by the source
Package widthDiffers	620 mm	643 mm
Package depthDiffers	170 mm	140 mm
Package heightDiffers	455 mm	435 mm
Package weightDiffers	8.4 kg	7.56 kg
Operational conditionsidentical
Operating temperature (T-T)	0 - 35 °C	0 - 35 °C
Operating relative humidity (H-H)	20 - 90%	20 - 90%
Certificatesidentical
Compliance certificates	RoHS	RoHS
CertificationKnown for one	CE, CB, UL/CUL, FCC-B (including ICES003, FCC-C,IC RSS-210, China CCC, CEL Gost-R, FAC, WEEE, REACH, SVHC, ErP, Argentina CNC	Unknown — not stated by the source
Packaging contentidentical
Mouse included	No	No
Keyboard included	No	No
AC adapter includedKnown for one	Yes	Unknown — not stated by the source
Cables includedKnown for one	HDMI, VGA	Unknown — not stated by the source
Power cord included	Yes	Yes
Quick start guide	Yes	Yes
Other featuresidentical
Autonomy mode	No	No
Detachable displayKnown for one	No	Unknown — not stated by the source
eMMC capacityKnown for one	Unknown — not stated by the source	16 GB

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
