PL PL171 1/2.3" Compact camera
16.1 MP CCD 4608 x 3456 pixels Black
Model PL171Part no. EC-PL171ZFDSE1EAN 8806071717364
107 specifications Checked today
- Display7.62 cm (3")
- Memory30 MB
- Battery740 mAh
- Weight113 g
- ColourBlack
- Camera typeCompact camera
Overview
- Display
- 7.62 cm (3")
- Memory
- 30 MB
- Battery
- 740 mAh
- Weight
- 113 g
- Colour
- Black
- Camera type
- Compact camera
- Brand
- Samsung
- Category
- Camera
- Model
- PL171
- Part numbers
- EC-PL171ZFDSE1, EC-PL171ZBDBE1, EC-PL171ZBDLE1, EC-PL171ZFDPE1
- EAN / UPC
- 8806071717364, 8806071313511, 8806071355597, 8806071350028 +1 more
- Also known as
- Samsung PL PL171 1/2.3" Compact camera 16.1 MP CCD 4608 x 3456 pixels Black
Specifications
107 specifications in 19 groups
Picture quality
| Specification | Value |
|---|---|
| Camera type | Compact camera |
| Megapixel (approx.) | 16.1 MP |
| Image sensor size | 1/2.3" |
| Sensor type | CCD |
| Maximum image resolution | 4608 x 3456 pixels |
| Still image resolution(s) | 1024 x 768,1920 x 1080,1984 x 1488,2592 x 1944,3648 x 2736,4608 x 2592,4608 x 3072,4608 x 3456 |
| Image stabilizer | Yes |
| Supported aspect ratios | 4:3, 16:9 |
| Total megapixels | 16.4 MP |
Lens system
| Specification | Value |
|---|---|
| Optical zoom | 5x |
| Digital zoom | 5x |
| Focal length range | 4.7 - 23.5 mm |
| Minimum focal length (35mm film equiv) | 26 mm |
| Maximum focal length (35mm film equiv) | 130 mm |
| Minimum aperture number | 3.3 |
| Maximum aperture number | 5.9 |
| Combined zoom | 25x |
Focusing
| Specification | Value |
|---|---|
| Focus | TTL |
| Focus adjustment | Auto |
| Auto focusing (AF) modes | Centre weighted Auto Focus, Multi Point Auto Focus |
| Auto Focus (AF) object detection | Face |
| Face tracking | Yes |
| Normal focusing range (tele) | 1.5 - ∞ |
| Normal focusing range (wide) | 0.8 - ∞ |
| Auto Mode focusing range (tele) | 1 - ∞ |
| Auto Mode focusing range (wide) | 0.05 - ∞ |
| Macro focusing range (tele) | 1 - 1.5 m |
| Macro focusing range (wide) | 0.05 - 0.8 m |
| Normal focusing range | 0.8 - ∞ |
Exposure
| Specification | Value |
|---|---|
| ISO sensitivity (min) | 80 |
| ISO sensitivity (max) | 3200 |
| ISO sensitivity | 80, 100, 200, 400, 800, 1600, 3200, Auto |
| Light exposure modes | Auto |
| Light exposure control | Program AE |
| Light exposure correction | ± 2EV (1/3EV step) |
| Light metering | Centre-weighted, Spot |
Shutter
| Specification | Value |
|---|---|
| Fastest camera shutter speed | 1/2000 s |
| Slowest camera shutter speed | 8 s |
Flash
| Specification | Value |
|---|---|
| Flash modes | Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization |
| Flash exposure correction | ±2EV (1/2, 1/3 EV step) |
| Flash range (tele) | 0.5 - 2 m |
| Flash range (wide) | 0.2 - 3.5 m |
| Flash recharging time | 4 s |
Video
| Specification | Value |
|---|---|
| Video recording | Yes |
| Maximum video resolution | 1280 x 720 pixels |
| HD type | HD |
| Video resolutions | 320 x 240,640 x 480,1280 x 720 |
| Analog signal format system | NTSC, PAL |
| Motion JPEG frame rate | 30 fps |
| Video formats supported | H.264, MP4, MPEG4 |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
| Voice recording | Yes |
| Audio formats supported | AAC, WAV |
Memory
| Specification | Value |
|---|---|
| Internal memory | 30 MB |
| Compatible memory cards | microSDHC |
| Memory slots | 1 |
| Maximum memory card size | 8 GB |
Display
| Specification | Value |
|---|---|
| Display | LCD |
| Display diagonal | 7.62 cm (3") |
| Display resolution (numeric) | 230000 pixels |
Ports & interfaces
| Specification | Value |
|---|---|
| PictBridge | Yes |
| USB version | 2.0 |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Bluetooth | No |
| Wi-Fi | No |
Camera
| Specification | Value |
|---|---|
| White balance | Auto, Cloudy, Daylight, Fluorescent, Tungsten |
| Scene modes | Backlight, Beach, Close-up (macro), Dawn, Documents, Fireworks, Night, Night landscape, Night portrait, Portrait, Self-portrait, Snow, Sunset, Landscape |
| Photo effects | Black&White, Negative film |
| Self-timer delay | 2,10 s |
| Contrast adjustment | Yes |
| Saturation adjustment | Yes |
| Camera playback | Movie, Single image, Slide show, Thumbnails |
| Camera file system | DCF 2.0, DPOF 1.1, Exif 2.1 |
| Image editing | Resizing, Rotating, Trimming |
| Image quality adjustment | Contrast, Saturation, Sharpness |
| Playback zoom (max) | 14.4x |
| Sharpness levels | Normal, Soft |
| Windows operating systems supported | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery voltage | 4.2 V |
| Battery capacity | 740 mAh |
| Battery type | BP70A |
| Number of batteries supported | 1 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 95.3 mm |
| Depth | 19 mm |
| Height | 57.3 mm |
| Weight | 113 g |
Packaging content
| Specification | Value |
|---|---|
| Hand strap | Yes |
| AC adapter included | Yes |
| Batteries included | Yes |
| Cables included | USB |
| Bundled software | Intelli-studio |
Other features
| Specification | Value |
|---|---|
| Minimum storage drive space | 250 MB |
| Minimum RAM | 512 MB |
| Minimum processor | Intel Pentium 4 3.2GHz/AMD Atlon FX 2.6GHz |
| Video capability | Yes |
| Aperture range (F-F) | 3.3 - 5.9 |
| Built-in flash | Yes |
| Camera shutter speed | 8 - 1/2000 s |
| Compatible operating systems | Windows XP SP2 Windows Vista Windows 7 |
| Focal length (35mm film equivalent) | 26 - 130 mm |
| HDMI ports quantity | 1 |
| Minimum system requirements | CD-ROM VGA 1024x768 USB 2.0 DirectX 9.0c+ Nvidia Geforce 7600GT, ATI Radeon X1600 |
| Power source type | Battery |
