PL 170 1/2.3" Compact camera
16.1 MP CCD 4608 x 3456 pixels Black
Model 170Part no. EC-PL170ZBPPMXEAN 8806071420325
93 specifications Checked today
- Display7.62 cm (3")
- Resolution320 x 240 pixels
- Memory27 MB
- Weight153.3 g
- ColourBlack
- Camera typeCompact camera
Overview
- Display
- 7.62 cm (3")
- Resolution
- 320 x 240 pixels
- Memory
- 27 MB
- Weight
- 153.3 g
- Colour
- Black
- Camera type
- Compact camera
- Brand
- Samsung
- Category
- Camera
- Model
- 170
- Part numbers
- EC-PL170ZBPPMX, EC-PL170ZFPBUS, EC-PL170ZFPBE2, EC-PL170ZFPLE2, EC-PL170ZFPPE2, EC-PL170ZFPSE2 +8 more
- EAN / UPC
- 8806071420325, 3610170533900
- Also known as
- Samsung PL 170 1/2.3" Compact camera 16.1 MP CCD 4608 x 3456 pixels Black
Specifications
93 specifications in 19 groups
Picture quality
| Specification | Value |
|---|---|
| Camera type | Compact camera |
| Megapixel (approx.) | 16.1 MP |
| Image sensor size | 1/2.3" |
| Sensor type | CCD |
| Maximum image resolution | 4608 x 3456 pixels |
| Still image resolution(s) | 1024 x 768,1984 x 1488,2592 x 1944,4608 x 2592,4608 x 3072 |
| Image stabilizer | Yes |
| Total megapixels | 16.4 MP |
Lens system
| Specification | Value |
|---|---|
| Optical zoom | 5x |
| Digital zoom | 5x |
| Focal length range | 4.7 - 23.5 mm |
| Minimum focal length (35mm film equiv) | 26 mm |
| Maximum focal length (35mm film equiv) | 130 mm |
| Minimum aperture number | 3.3 |
| Maximum aperture number | 5.9 |
| Extra/Smart zoom | 2x |
Focusing
| Specification | Value |
|---|---|
| Focus | TTL |
| Focus adjustment | Auto |
| Auto focusing (AF) modes | Centre weighted Auto Focus, Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus |
| Auto Focus (AF) object detection | Face |
| Face tracking | Yes |
| Normal focusing range (tele) | 1.5 - ∞ |
| Normal focusing range (wide) | 0.8 - ∞ |
| Macro focusing range (tele) | 1 - 1.5 m |
| Macro focusing range (wide) | 0.05 - 0.8 m |
| Normal focusing range | 0.8 - ∞/1.5 - ∞ |
Exposure
| Specification | Value |
|---|---|
| ISO sensitivity (min) | 80 |
| ISO sensitivity (max) | 3200 |
| ISO sensitivity | 80, 100, 200, 400, 800, 1600, 3200, Auto |
| Light exposure modes | Auto |
| Light exposure control | Program AE |
| Light exposure correction | ± 2EV (1/3EV step) |
| Light metering | Centre-weighted, Spot |
Shutter
| Specification | Value |
|---|---|
| Fastest camera shutter speed | 1/2000 s |
| Slowest camera shutter speed | 8 s |
Flash
| Specification | Value |
|---|---|
| Flash modes | Auto, Fill-in, Flash off, Flash on, Red-eye reduction, Slow synchronization |
| Flash range (tele) | 0.5 - 2 m |
| Flash range (wide) | 0.2 - 3.5 m |
| Flash recharging time | 4 s |
Video
| Specification | Value |
|---|---|
| Video recording | Yes |
| Maximum video resolution | 1280 x 720 pixels |
| HD type | HD |
| Video resolutions | 320 x 240,640 x 480 pixels |
| Analog signal format system | NTSC, PAL |
| Motion JPEG frame rate | 30 fps |
| Video formats supported | H.264, MPEG4 |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
| Audio formats supported | AAC |
Memory
| Specification | Value |
|---|---|
| Internal memory | 27 MB |
| Compatible memory cards | microSDHC |
| Memory slots | 1 |
| Maximum memory card size | 8 GB |
Display
| Specification | Value |
|---|---|
| Display | LCD |
| Display diagonal | 7.62 cm (3") |
| Display resolution | 320 x 240 pixels |
| Display resolution (numeric) | 230000 pixels |
| Second display | Yes |
| Second display diagonal | 3.81 cm (1.5") |
Ports & interfaces
| Specification | Value |
|---|---|
| PictBridge | Yes |
| USB version | 2.0 |
Camera
| Specification | Value |
|---|---|
| White balance | Auto, Cloudy, Custom modes, Daylight, Fluorescent, Tungsten |
| Scene modes | Backlight, Beach, Children, Close-up (macro), Dawn, Documents, Fireworks, Night, Night portrait, Portrait, Self-portrait, Snow, Sunset, Landscape |
| Shooting modes | Movie, Scene |
| Self-timer delay | 2,10 s |
| Contrast adjustment | Yes |
| Saturation adjustment | Yes |
| Camera playback | Movie, Single image |
| Camera file system | DCF 2.0, DPOF 1.1, Exif 2.21 |
| Custom colour | Yes |
| Image editing | Resizing, Rotating, Trimming |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Tripod mounting supported | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery type | BP70A |
System requirements
| Specification | Value |
|---|---|
| Mac compatibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 95.3 mm |
| Depth | 19 mm |
| Height | 57.3 mm |
| Weight | 153.3 g |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | Intelli Studio |
Other features
| Specification | Value |
|---|---|
| Minimum storage drive space | 110 MB |
| Minimum RAM | 256 MB |
| Minimum processor | Power Mac G3 |
| Video capability | Yes |
| Built-in flash | Yes |
| Compatible operating systems | Mac OS 10.4+ Windows XP/Vista/7 |
| Digital SLR | No |
| Frame | Yes |
| HDMI ports quantity | 1 |
| Power source type | Battery |
