Canon SX540 HS
Canon

SX540 HS

Model SX540 HS

136 specifications Checked today
  • Display7.62 cm (3")
  • ColourBlack
  • Camera typeBridge camera
  • Optical zoom50x
  • FocusTTL
  • ISO sensitivity (min)80
See all specifications

Overview

Display
7.62 cm (3")
Colour
Black
Camera type
Bridge camera
Optical zoom
50x
Focus
TTL
ISO sensitivity (min)
80
Brand
Canon
Category
Camera
Model
SX540 HS
Also known as
Canon PowerShot SX540 HS 1/2.3" Bridge camera 20.3 MP CMOS 5184 x 3888 pixels Black

Specifications

136 specifications in 22 groups

Picture quality

Camera typeBridge camera
Megapixel (approx.)20.3 MP
Image sensor size1/2.3"
Sensor typeCMOS
Maximum image resolution5184 x 3888 pixels
Still image resolution(s)4:3 - (L) 5184 x 3888, (M) 2592 x 1944, (M1) 3648 x 2736, (M2) 2048 x 1536, (S) 640 x 480 16:9 - (L) 5184 x 2912, (M1) 3648 x 2048, (M2) 1920 x 1080, (S) 640 x 360 3:2 - (L) 5184 x 3456, (M1) 3648 x 2432, (M2) 2048 x 1368, (S) 640 x 424 1:1 - (L) 3888 x 3888, (M1) 2736 x 2736, (M2) 1536 x 1536, (S)
Image stabilizerYes
Image stabilizer locationLens
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Total megapixels21.1 MP
Image formats supportedJPEG

Lens system

Optical zoom50x
Digital zoom4x
Focal length range4.3 - 215 mm
Minimum focal length (35mm film equiv)24 mm
Maximum focal length (35mm film equiv)1200 mm
Minimum aperture number3.4
Maximum aperture number6.5
Extra/Smart zoom100x
Lens structure (elements/groups)13/10
Number of aspheric elements13

Focusing

FocusTTL
Focus adjustmentAuto/Manual
Auto focusing (AF) modesAI Focus
Auto Focus (AF) object detectionFace
Auto Focus (AF) points9
Auto Focus (AF) points selectionManual
Smile detectionYes
Auto Focus (AF) assist beamYes
Auto Focus (AF) lockYes

Exposure

ISO sensitivity (min)80
ISO sensitivity (max)3200
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200
Light exposure modesAuto, Manual
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
Auto Exposure (AE) lockYes

Shutter

Fastest camera shutter speed1/2000 s
Slowest camera shutter speed15 s
Camera shutter typeElectronic

Flash

Flash modesAuto, Flash off, Flash on, Manual, Slow synchronization
Flash exposure compensationYes
Flash exposure correction±2EV (1/3 EV step)
Flash exposure lockYes
Flash range (tele)1.3 - 3 m
Flash range (wide)0.5 - 5.5 m
Flash sync-speed1/2000 s

Video

Video recordingYes
Maximum video resolution1920 x 1080 pixels
HD typeFull HD
Video resolutions640 x 480,1280 x 720,1920 x 1080
Video recording time300 min
Analog signal format systemNTSC, PAL
Motion JPEG frame rate59.94 fps
Resolution at capture speed1920x1080@30fps
Video formats supportedH.264, MP4, MPEG4

Audio

Built-in microphoneYes
Voice recordingYes
Audio formats supportedLC-AAC, MP4
Audio systemstereo

Memory

Compatible memory cardsSD, SDHC, SDXC
Memory slots2

Display

DisplayTFT
TouchscreenNo
Display diagonal7.62 cm (3")
Display diagonal (metric)7.5 cm
Display resolution (numeric)461000 pixels
Flip-out screenNo
Field of view100%
Second displayNo
Vari-angle LCD displayNo

Ports & interfaces

PictBridgeYes
USB version2.0
USB connectorMini-USB B
HDMIYes
HDMI connector typeMini
Headphone outputs1
USB portYes

Network

BluetoothNo
Wi-FiYes
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Near Field Communication (NFC)Yes

Camera

White balanceAuto, Cloudy, Custom modes, Daylight, Fluorescent, Fluorescent H, Tungsten
Scene modesFireworks, Portrait
Shooting modesAperture priority, Auto, Shutter priority
Photo effectsBlack&White, Neutral, Positive film, Sepia, Skin tones, Vivid
Self-timer delay2,10 s
Contrast adjustmentYes
Brightness adjustmentYes
Camera file systemDCF, DPOF 1.1
Direct printingYes
GPS (satellite)Yes
HistogramYes
Languages supportMulti
Orientation sensorYes
Playback zoom (max)10x
Tripod mounting supportedYes
Image processorDIGIC 6
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.9 Mavericks
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home

Design

Product colourBlack
CertificationCE

Battery

Battery technologyLithium-Ion (Li-Ion)
Battery life (CIPA standard)205 shots
Battery typeNB-6LH
Number of batteries supported1

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%

Weight & dimensions

Width120 mm
Depth91.9 mm
Height81.7 mm
Weight (including battery)442 g

Packaging data

Package width158.5 mm
Package depth177.5 mm
Package height129.5 mm
Package weight954 g

Packaging content

Hand strapYes
Batteries includedYes
Battery charger includedYes
Cables includedAC
Lens cap includedYes
Quick start guideYes
Software CDYes
Bundled softwareCameraWindow DC, Map Utility, Image Transfer Utility

Logistics data

Pallet gross weight150 kg
Master (outer) cases per pallet5 pc(s)
Layers per pallet5 pc(s)
Products per pallet200 pc(s)
Master (outer) case width336 mm
Master (outer) case length413 mm
Master (outer) case height215 mm
Master (outer) case gross weight6.51 kg
Products per master (outer) case6 pc(s)

Other features

Power source typeBattery

Technical details

Self-timerYes
