7D + EF-S 17-55mm
Model 7D + EF-S 17-55mmPart no. 3814B131
92 specifications Checked today
- Display7.62 cm (3")
- Weight820 g
- ColourBlack
- Camera typeSLR Camera Kit
- Focal length range17 - 55 mm
- FocusTTL
Overview
- Display
- 7.62 cm (3")
- Weight
- 820 g
- Colour
- Black
- Camera type
- SLR Camera Kit
- Focal length range
- 17 - 55 mm
- Focus
- TTL
- Brand
- Canon
- Category
- Camera
- Model
- 7D + EF-S 17-55mm
- Part number
- 3814B131
- Also known as
- Canon EOS 7D + EF-S 17-55mm SLR Camera Kit 18 MP CMOS 5184 x 3456 pixels Black
Specifications
92 specifications in 19 groups
Picture quality
| Specification | Value |
|---|---|
| Camera type | SLR Camera Kit |
| Megapixel (approx.) | 18 MP |
| Sensor type | CMOS |
| Maximum image resolution | 5184 x 3456 pixels |
| Still image resolution(s) | JPEG: 5184x3456, 3456x2304, 2592x1728 RAW: 5184x3456, 3888x2592, 2592x1728 |
| Image stabilizer | No |
| Supported aspect ratios | 3:2 |
| Total megapixels | 19 MP |
| Image sensor size (W x H) | 22.3 x 14.9 mm |
| Image formats supported | JPG, Raw |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 17 - 55 mm |
| Lens structure (elements/groups) | 19/12 |
| Filter size | 77 mm |
| Lens mount interface | Canon EF, Canon EF-S |
Focusing
| Specification | Value |
|---|---|
| Focus | TTL |
| Focus adjustment | Auto/Manual |
| Auto focusing (AF) modes | Spot Auto Focus |
| Auto Focus (AF) points | 19 |
| Auto Focus (AF) points selection | Auto, Manual |
| Closest focusing distance | 0.35 m |
| Auto Focus (AF) assist beam | Yes |
| Auto Focus (AF) lock | Yes |
Exposure
| Specification | Value |
|---|---|
| ISO sensitivity | 100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400, Auto |
| Light exposure correction | ±5EV (1/2; 1/3 EV step) |
| Light metering | Centre-weighted, Evaluative (Multi-pattern), Spot |
| Auto Exposure (AE) lock | Yes |
Shutter
| Specification | Value |
|---|---|
| Fastest camera shutter speed | 1/8000 s |
| Slowest camera shutter speed | 30 s |
| Camera shutter type | Electronic |
Flash
| Specification | Value |
|---|---|
| Flash modes | Auto, Manual |
| Flash exposure compensation | Yes |
| Flash exposure correction | ±3EV (1/2; 1/3 EV step) |
| Flash exposure lock | Yes |
| Flash recharging time | 3 s |
| Flash sync-speed | 1/250 s |
Video
| Specification | Value |
|---|---|
| Video recording | Yes |
| Maximum video resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Video resolutions | 640 x 480,1280 x 720,1920 x 1080 |
| Analog signal format system | NTSC, PAL |
| Resolution at capture speed | 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 640x480@60fps |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
Memory
| Specification | Value |
|---|---|
| Compatible memory cards | CF |
Display
| Specification | Value |
|---|---|
| Display | LCD |
| Display diagonal | 7.62 cm (3") |
| Display resolution (numeric) | 920000 pixels |
| Display aspect ratio | 3:2 |
| Field of view | 100% |
Viewfinder
| Specification | Value |
|---|---|
| Viewfinder type | Optical |
| Magnification | 1x |
Ports & interfaces
| Specification | Value |
|---|---|
| PictBridge | Yes |
| USB version | 2.0 |
| HDMI | Yes |
| HDMI connector type | Mini |
| Microphone in | Yes |
Camera
| Specification | Value |
|---|---|
| White balance | Auto |
| Self-timer delay | 2,10 s |
| Brightness adjustment | Yes |
| Dioptre correction | Yes |
| Histogram | Yes |
| Languages support | Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Swedish, Thai, Turkish, Ukrainian |
| Live view | Yes |
| Orientation sensor | Yes |
| Playback zoom (max) | 10x |
| Start-up time | 100 ms |
| Image processor | 2 x DIGIC 4 |
| Mac operating systems supported | Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion |
| Windows operating systems supported | Yes |
| Compatible products | E-TTL II with EX series Speedlites, wireless multi-flash support |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Dustproof | Yes |
| Waterproof | Yes |
| Material | Magnesium |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery life (CIPA standard) | 750 shots |
| Battery level indicator | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 148.2 mm |
| Depth | 73.5 mm |
| Height | 110.7 mm |
| Weight | 820 g |
| Lens diameter | 8.35 cm |
| Lens length | 11.1 cm |
| Lens weight | 645 g |
Packaging content
| Specification | Value |
|---|---|
| Hand strap | Yes |
| AC adapter included | Yes |
| Batteries included | Yes |
| Carrying case | Yes |
| Bundled software | ImageBrowser EX, Digital Photo Professional, PhotoStitch, EOS Utility, Picture Style Editor |
Other features
| Specification | Value |
|---|---|
| Built-in flash | Yes |
| Power source type | AC, Battery |
