760D + EF-S 18-135mm
Model 760D + EF-S 18-135mmPart no. 0021C023EAN 4549292028638
105 specifications Checked today
- Display7.62 cm (3")
- ColourBlack
- Camera typeSLR Camera Kit
- Focal length range18 - 135 mm
- FocusTTL-CT-SIR
- ISO sensitivity (min)100
Overview
- Display
- 7.62 cm (3")
- Colour
- Black
- Camera type
- SLR Camera Kit
- Focal length range
- 18 - 135 mm
- Focus
- TTL-CT-SIR
- ISO sensitivity (min)
- 100
- Brand
- Canon
- Category
- Camera
- Model
- 760D + EF-S 18-135mm
- Part numbers
- 0021C023, 0021C005
- EAN / UPC
- 4549292028638, 3662362045449, 4549292023855, 8714574628158
- Also known as
- Canon EOS 760D + EF-S 18-135mm SLR Camera Kit 24.2 MP CMOS 6000 x 4000 pixels Black
Specifications
105 specifications in 19 groups
Picture quality
| Specification | Value |
|---|---|
| Camera type | SLR Camera Kit |
| Megapixel (approx.) | 24.2 MP |
| Sensor type | CMOS |
| Maximum image resolution | 6000 x 4000 pixels |
| Still image resolution(s) | 6000x4000, 3984x2656, 2976x1984, 1920x1280, 720x480, 5328x4000, 3552x2664, 2656x1992, 1696x1280, 640x480, 6000x3368, 3984x2240, 1976x1680, 1920x1080, 720x480, 4000x4000, 2656x2656, 1984x1984, 1280x1280, 480x480 |
| Image stabilizer | No |
| Supported aspect ratios | 1:1, 3:2, 4:3, 16:9 |
| Total megapixels | 24.7 MP |
| Image sensor size (W x H) | 22.3 x 14.9 mm |
| Image formats supported | JPG, Raw |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 18 - 135 mm |
| Minimum focal length (35mm film equiv) | 29 mm |
| Maximum focal length (35mm film equiv) | 216 mm |
| Minimum aperture number | 3.5 |
| Maximum aperture number | 38 |
| Lens structure (elements/groups) | 16/12 |
| Filter size | 67 mm |
| Number of diaphragm blades | 7 |
| Lens mount interface | Canon EF, Canon EF-S |
Focusing
| Specification | Value |
|---|---|
| Focus | TTL-CT-SIR |
| Focus adjustment | Auto/Manual |
| Auto focusing (AF) modes | Servo Auto Focus, Single Auto Focus |
| Auto Focus (AF) points | 19 |
| Closest focusing distance | 0.39 m |
| Auto Focus (AF) assist beam | Yes |
| Auto Focus (AF) lock | Yes |
Exposure
| Specification | Value |
|---|---|
| ISO sensitivity (min) | 100 |
| ISO sensitivity (max) | 25600 |
| ISO sensitivity | 100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto |
| Light exposure modes | Auto, Manual |
| Light exposure control | Program AE |
| Light exposure correction | ±5EV (1/2; 1/3 EV step) |
| Light metering | Centre-weighted, Evaluative (Multi-pattern), Partial, Spot |
| Auto Exposure (AE) lock | Yes |
Shutter
| Specification | Value |
|---|---|
| Slowest camera shutter speed | 30 s |
| Camera shutter type | Electronic |
Flash
| Specification | Value |
|---|---|
| Flash modes | Auto, Manual, Red-eye reduction |
| Flash exposure compensation | Yes |
| Flash exposure correction | ±2EV (1/2, 1/3 EV step) |
| Flash exposure lock | Yes |
| Flash guide number | 12 m |
| Flash recharging time | 3 s |
| Flash sync-speed | 1/200 s |
Video
| Specification | Value |
|---|---|
| Video recording | Yes |
| Maximum video resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Video resolutions | 640 x 480,1280 x 720,1920 x 1080 |
| Analog signal format system | NTSC, PAL |
| Motion JPEG frame rate | 59.94 fps |
| Resolution at capture speed | 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 640x480@25fps, 640x480@30fps |
| Video formats supported | MP4 |
Audio
| Specification | Value |
|---|---|
| Noise reduction | Yes |
Memory
| Specification | Value |
|---|---|
| Compatible memory cards | SD, SDHC, SDXC |
| Memory slots | 1 |
Display
| Specification | Value |
|---|---|
| Display | TFT |
| Touchscreen | Yes |
| Display diagonal | 7.62 cm (3") |
| Display resolution (numeric) | 1040000 pixels |
| Display aspect ratio | 3:2 |
| Field of view | 100% |
Viewfinder
| Specification | Value |
|---|---|
| Magnification | 0.82x |
Ports & interfaces
| Specification | Value |
|---|---|
| PictBridge | Yes |
| USB version | 2.0 |
| HDMI | Yes |
| HDMI connector type | Mini |
| Headphone outputs | 1 |
Camera
| Specification | Value |
|---|---|
| White balance | Cloudy, Custom modes, Daylight, Flash, Shade, Tungsten |
| Scene modes | Close-up (macro), Night portrait, Portrait, Sports, Landscape |
| Shooting modes | Aperture priority, Auto, Manual, Program, Shutter priority |
| Photo effects | Black&White, Neutral |
| Self-timer delay | 2,10 s |
| Camera playback | Movie, Single image, Slide show |
| Diopter adjustment (D-D) | -3 - 1 |
| Dioptre correction | Yes |
| Camera file system | DPOF 1.1, Exif 2.3, Raw |
| Histogram | Yes |
| Languages support | Multi |
| Live view | Yes |
| Orientation sensor | Yes |
| Playback zoom (max) | 10x |
| Image processor | DIGIC 6 |
| Mac operating systems supported | Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Material | Aluminium, Glass, Polycarbonate |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery life (CIPA standard) | 440 shots |
| Battery type | LP-E17 |
| Number of batteries supported | 1 |
| Battery level indicator | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 131.9 mm |
| Depth | 77.8 mm |
| Height | 100.9 mm |
| Weight (including battery) | 565 g |
| Lens diameter | 7.66 cm |
| Lens length | 9.6 cm |
| Lens weight | 480 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Batteries included | Yes |
| Quick start guide | Yes |
| Bundled software | Digital Photo Professional, EOS Utility, Picture Style Editorf |
Other features
| Specification | Value |
|---|---|
| Built-in flash | Yes |
| Power source type | Battery |
