230 HS
Model 230 HSPart no. 5702B011EAN 8714574578101
88 specifications Checked today
- Display7.62 cm (3")
- ColourSilver
- Camera typeCompact camera
- Optical zoom8x
- FocusTTL
- ISO sensitivity (min)100
Overview
- Display
- 7.62 cm (3")
- Colour
- Silver
- Camera type
- Compact camera
- Optical zoom
- 8x
- Focus
- TTL
- ISO sensitivity (min)
- 100
- Brand
- Canon
- Category
- Camera
- Model
- 230 HS
- Part numbers
- 5702B011, 5270B006, 5693B006, 5699B006, 5270B009, 5693B009 +30 more
- EAN / UPC
- 8714574578101, 8714574573410, 8714574573496, 8714574573663 +40 more
- Also known as
- Canon Digital IXUS 230 HS 1/2.3" Compact camera 12.1 MP CMOS 4000 x 3000 pixels Silver
Specifications
88 specifications in 17 groups
Picture quality
| Specification | Value |
|---|---|
| Camera type | Compact camera |
| Megapixel (approx.) | 12.1 MP |
| Image sensor size | 1/2.3" |
| Sensor type | CMOS |
| Maximum image resolution | 4000 x 3000 pixels |
| Still image resolution(s) | 480 x 480,640 x 360,640 x 424,640 x 480,1200 x 1200,1600 x 1064,1600 x 1200,1920 x 1080,2112 x 2112,2816 x 1584,2816 x 1880,2816 x 2112,2992 x 2992,4000 x 2240,4000 x 2664 |
| Image stabilizer | Yes |
| Supported aspect ratios | 3:2, 4:3, 16:9 |
Lens system
| Specification | Value |
|---|---|
| Optical zoom | 8x |
| Digital zoom | 4x |
| Focal length range | 5 - 40 mm |
| Minimum focal length (35mm film equiv) | 28 mm |
| Maximum focal length (35mm film equiv) | 224 mm |
| Minimum aperture number | 3 |
| Maximum aperture number | 5.9 |
| Lens structure (elements/groups) | 8/7 |
| Combined zoom | 32x |
| Number of aspheric elements | 3 |
Focusing
| Specification | Value |
|---|---|
| Focus | TTL |
| Focus adjustment | Auto |
| Auto focusing (AF) modes | Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus |
| Auto Focus (AF) object detection | Face |
| Face tracking | Yes |
| Closest focusing distance | 0.01 m |
| Auto Focus (AF) assist beam | Yes |
| Auto Focus (AF) lock | Yes |
Exposure
| Specification | Value |
|---|---|
| ISO sensitivity (min) | 100 |
| ISO sensitivity (max) | 3200 |
| ISO sensitivity | 100, 200, 400, 800, 1600, 3200, Auto |
| Light exposure modes | Auto |
| Light exposure correction | ± 2EV (1/3EV step) |
| Light metering | Centre-weighted, Spot |
| Auto Exposure (AE) lock | Yes |
Shutter
| Specification | Value |
|---|---|
| Fastest camera shutter speed | 1/2000 s |
| Slowest camera shutter speed | 15 s |
Flash
| Specification | Value |
|---|---|
| Flash modes | Auto, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization |
| Flash exposure lock | Yes |
| Flash range (tele) | 0.5 - 2 m |
| Flash range (wide) | 0.5 - 4 m |
Video
| Specification | Value |
|---|---|
| Video recording | Yes |
| Maximum video resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Video resolutions | 640 x 480,1280 x 720 pixels |
| Analog signal format system | NTSC, PAL |
| Motion JPEG frame rate | 24 fps |
| Video formats supported | H.264, MOV |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
Memory
| Specification | Value |
|---|---|
| Compatible memory cards | SD, SDHC, SDXC |
Display
| Specification | Value |
|---|---|
| Display | LCD |
| Display diagonal | 7.62 cm (3") |
| Display resolution (numeric) | 461000 pixels |
| Field of view | 100% |
Ports & interfaces
| Specification | Value |
|---|---|
| PictBridge | Yes |
| USB version | 2.0 |
Camera
| Specification | Value |
|---|---|
| White balance | Auto, Cloudy, Custom modes, Daylight, Fluorescent, Tungsten |
| Scene modes | Beach, Children, Fireworks, Night, Portrait, Self-portrait, Snow |
| Photo effects | Black&White, Neutral, Positive film, Sepia, Skin tones, Vivid |
| Self-timer delay | 2,10 s |
| Camera playback | Movie, Single image |
| Multi burst mode | Yes |
| Camera file system | DPOF 1.1, Exif 2.3 |
| Custom colour | Yes |
| Histogram | Yes |
| Image editing | Resizing |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Swedish, Thai, Turkish, Ukrainian |
| Orientation sensor | Yes |
| Playback zoom (max) | 10x |
| Image processor | DIGIC 4 |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery life (CIPA standard) | 210 shots |
| Battery type | NB-4L |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 95.8 mm |
| Depth | 22.1 mm |
| Height | 56.8 mm |
| Weight (including battery) | 140 g |
Other features
| Specification | Value |
|---|---|
| Video capability | Yes |
| Built-in flash | Yes |
| Camera shutter speed | 1 - 1/2000; 15 - 1/2000 s |
| Compatible operating systems | Windows 7 / 7 SP1 / Vista SP2 / XP SP3 Mac OS X v10.5 – 10.6 |
| Digital SLR | No |
| Focal length (35mm film equivalent) | 5 - 40 mm |
| Frame | Yes |
| HDMI ports quantity | 1 |
| Power source type | Battery |
| Video memory capacity | 4GB |
