Xonar U7 MKII
Model Xonar U7 MKIIPart no. XONAR U7 MKIIEAN 889349481394
26 specifications
- ColourBlack
- InternalNo
- Host interfaceUSB
- LED indicatorsStatus
- Mac compatibilityYes
- Depth80 mm
Overview
- Colour
- Black
- Internal
- No
- Host interface
- USB
- LED indicators
- Status
- Mac compatibility
- Yes
- Depth
- 80 mm
- Brand
- ASUS
- Category
- Audio Card
- Model
- Xonar U7 MKII
- Part numbers
- XONAR U7 MKII, 90YB00KB-M0UC00
- EAN / UPC
- 889349481394, 4712900481396
- Also known as
- ASUS Xonar U7 MKII 7.1 channels USB
Specifications
26 specifications in 7 groups
Audio
| Specification | Value |
|---|---|
| Internal | No |
| Audio output channels | 7.1 channels |
| Audio quality | 24 bit |
| Line-out Signal-to-Noise Ratio (SNR) | 114 dB |
| Line-in Signal-to-Noise Ratio (SNR) | 110 dB |
| Frequency range | 10 - 46000 Hz |
| Line-out Total Harmonic Distortion (THD) | 0.0006% |
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | USB |
| Line-in | Yes |
| Line-out | Yes |
| Headphone outputs | 1 |
| S/PDIF out port | Yes |
| USB 2.0 ports quantity | 1 |
| Audio (L/R) out | 1 |
| Subwoofer out | Yes |
| Plug and Play | Yes |
Features
| Specification | Value |
|---|---|
| LED indicators | Status |
| Product colour | Black |
| Cables included | S/PDIF, USB |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 H |
| Mac compatibility | Yes |
System requirements
| Specification | Value |
|---|---|
| USB required | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 80 mm |
| Width | 130 mm |
| Height | 25 mm |
Other features
| Specification | Value |
|---|---|
| Quick start guide | Yes |
