Essence STX II 7.1
Model Essence STX II 7.1Part no. ESSENCE STX II 7.1
22 specifications
- ColourBlack
- InternalYes
- Host interfacePCI-E
- ChipsetASUS AV100
- Depth168 mm
- Channels quantity7.1 channels
Overview
- Colour
- Black
- Internal
- Yes
- Host interface
- PCI-E
- Chipset
- ASUS AV100
- Depth
- 168 mm
- Channels quantity
- 7.1 channels
- Brand
- ASUS
- Category
- Audio Card
- Model
- Essence STX II 7.1
- Part number
- ESSENCE STX II 7.1
- Also known as
- ASUS Essence STX II 7.1 Internal 7.1 channels PCI-E
Specifications
22 specifications in 6 groups
Audio
| Specification | Value |
|---|---|
| Internal | Yes |
| Audio output channels | 7.1 channels |
| Audio quality | 24 bit |
| Line-out Signal-to-Noise Ratio (SNR) | 124 dB |
| Line-in Signal-to-Noise Ratio (SNR) | 118 dB |
| Audio A/D Converter (ADC) | 24-bit/192kHz |
| Digital-to-Analog Conversion (DAC) | 24-bit/192kHz |
| Frequency range | 10 - 90000 Hz |
| Line-out Total Harmonic Distortion (THD) | 0.0003% |
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | PCI-E |
| Line-in | Yes |
| Line-out | Yes |
| Headphone outputs | 1 |
| S/PDIF out port | Yes |
Features
| Specification | Value |
|---|---|
| Dolby technologies | Dolby Digital Live, Dolby Headphone, Dolby Pro-Logic IIx, Dolby Virtual Speaker |
| Chipset | ASUS AV100 |
| Product colour | Black |
| Cables included | Audio (3.5mm), RCA |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 168 mm |
| Width | 107 mm |
Technical details
| Specification | Value |
|---|---|
| Channels quantity | 7.1 channels |
