Shuttle X50V6 Intel® Celeron® 3865U
Shuttle

X50V6 Intel® Celeron® 3865U

39.6 cm (15.6") 1366 x 768 pixels Touchscreen All-in-One PC barebone Black

Model X50V6Part no. PAB-X50V601EAN 887993001227

104 specifications
  • Display39.6 cm (15.6")
  • Resolution1366 x 768 pixels
  • ProcessorIntel® Celeron®
  • TypeAll-in-One PC barebone
  • OSNo
  • ColourBlack
See all specifications

Overview

Display
39.6 cm (15.6")
Resolution
1366 x 768 pixels
Processor
Intel® Celeron®
Type
All-in-One PC barebone
OS
No
Colour
Black
Brand
Shuttle
Model
X50V6
Part numbers
PAB-X50V601, PAB-X50V602
EAN / UPC
887993001227, 688939215926, 887993001197, 887993001203 +1 more
Also known as
Shuttle X50V6 Intel® Celeron® 3865U 39.6 cm (15.6") 1366 x 768 pixels Touchscreen All-in-One PC barebone Black

Specifications

104 specifications in 20 groups

Display

Display diagonal39.6 cm (15.6")
Display resolution1366 x 768 pixels
TouchscreenYes
HD typeHD
Display brightness220 cd/m²
Panel typeLCD

Processor

Processor manufacturerIntel
Processor familyIntel® Celeron®
Processor model3865U
Processor cores2
Processor threads2
Processor frequency1.8 GHz
Processor socketBGA 1356
Thermal Design Power (TDP)15 W
Configurable TDP-down10 W
Bus typeOPI
PCI Express configurations1x2+2x1, 1x4, 2x2, 4x1
PCI Express slots version2.0
Processor codenameKaby Lake
Processor lithography14 nm
Conflict-Free processorYes

Memory

Maximum internal memory32 GB
Memory slots typeSO-DIMM
Supported memory clock speeds2133 MHz
ECCNo

Storage

Number of storage drives supported1
Card reader integratedYes
Compatible memory cardsSD, SDHC, SDXC

Graphics

On-board graphics cardYes
On-board graphics card modelIntel® HD Graphics 610

Audio

Built-in speaker(s)Yes
Number of speakers2
RMS rated power2 W

Network

Wi-FiYes
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LANYes

Ports & interfaces

Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
HDMI ports quantity1
HDMI version1.4
VGA (D-Sub) ports quantity1
Headphone outputs1
Microphone inYes
DC-in jackYes

Design

Product colourBlack
Cable lock slotYes
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
VESA mountingYes
Country of originChina

Performance

Product typeAll-in-One PC barebone
Motherboard chipsetIntel SoC

Software

Operating system installedNo

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Enhanced Halt StateYes
Intel Flex Memory AccessYes
Intel Secure Key Technology version1.00
Intel Smart Response Technology version1.00
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)No
Intel Stable Image Platform Program (SIPP) version0.00
Intel TSX-NINo
Intel TSX-NI version0.00
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® My WiFi Technology (Intel® MWT)Yes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Smart Response TechnologyYes
Intel® Turbo Boost TechnologyNo
Thermal Monitoring TechnologiesYes

Power

AC adapter output voltage19 V

Weight & dimensions

Package weight4.8 kg

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%

Certificates

CertificationCE, FCC, BSM, RoHS, ErP Lot6

Sustainability

Sustainability certificatesENERGY STAR

Packaging content

AC adapter includedYes
Drivers includedYes
Power cord includedYes
Quick start guideYes

Logistics data

Harmonized System (HS) code84714100

Other features

Graphics card familyIntel
AC adapter output current3.42 A
Chassis typeAll-in-One
Compatible operating systems- Windows 10 64-bit - Linux 64-bit
Compatible processor seriesIntel® Celeron®, Intel® Pentium®
Power supply65 W
Power supply typeExternal AC adapter
SafetyCB, BSMI, ETL
Storage drive interfaceSerial ATA III
