Inspiron 7777 Intel® Core™ i5 i5-8400T

68.6 cm (27") 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 1 TB HDD Windows 10 Home Wi-Fi 5 (802.11ac) Black, Gr

Model 7777Part no. SMI7777W10HS7245TEAN 5397184074169

216 specifications

Display68.6 cm (27")
Resolution1920 x 1080 pixels
ProcessorIntel® Core™ i5
Memory8 GB
Storage1 TB
GraphicsNot available

See all specifications

Overview

Display: 68.6 cm (27")
Resolution: 1920 x 1080 pixels
Processor: Intel® Core™ i5
Memory: 8 GB
Storage: 1 TB
Graphics: Not available

Brand: Dell
Category: All-in-One PCs/Workstations
Model: 7777
Part numbers: SMI7777W10HS7245T, SMI7777W10HS7225, B210531AU, B220531AU, FDCWMAGC725S, 7JVPW +34 more
EAN / UPC: 5397184074169, 5397184192207, 5397184192214, 5397184119747 +12 more
Also known as: DELL Inspiron 7777 Intel® Core™ i5 i5-8400T 68.6 cm (27") 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 1 TB HDD Windows 10 Home Wi-Fi 5 (802.11ac) Black, Gr

Specifications

216 specifications in 25 groups

Display

Specification	Value
Display diagonal	68.6 cm (27")
Display resolution	1920 x 1080 pixels
Touchscreen	No
HD type	Full HD
LED backlight	Yes
Native aspect ratio	16:9
Panel type	IPS
Pixel pitch	0.3114 x 0.3114 mm
Screen shape	Flat
Tilt angle range	-5 - 30°

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	8th gen Intel® Core™ i5
Processor model	i5-8400T
Processor cores	6
Processor threads	6
Processor boost frequency	3.3 GHz
Processor frequency	1.7 GHz
Processor cache	9 MB
Processor cache type	Smart Cache
Processor socket	LGA 1151 (Socket H4)
System bus rate	8 GT/s
Thermal Design Power (TDP)	35 W
Configurable TDP-down frequency	1.2 GHz
Configurable TDP-down	25 W
Bus type	DMI3
Maximum number of PCI Express lanes	16
PCI Express configurations	1x16, 1x8+2x4, 2x8
PCI Express slots version	3.0
Processor code	SR3X6
Processor codename	Coffee Lake
Processor lithography	14 nm
Processor operating modes	64-bit
Stepping	U0
Tjunction	100 °C
Conflict-Free processor	Yes
Maximum internal memory supported by processor	64 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Memory channels supported by processor	Dual
ECC supported by processor	No

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	2666 MHz
Memory layout (slots x size)	1 x 8 GB
Memory form factor	DIMM/SO-DIMM

Storage

Specification	Value
Total storage capacity	1 TB
Storage media	HDD
Number of storage drives installed	1
Number of HDDs installed	1
HDD capacity	1 TB
HDD speed	7200 RPM
HDD size	2.5"
HDD interface	SATA III
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	SD, SDHC, SDXC

Graphics

Specification	Value
Discrete graphics card	No
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card family	Intel® UHD Graphics
On-board graphics card model	Intel® UHD Graphics 630
Maximum on-board graphics card memory	64 GB
Number of displays supported (on-board graphics)	3
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1050 MHz
On-board graphics card 4K support	Yes
On-board graphics card DirectX version	12.0
On-board graphics card ID	0x3E92
On-board graphics card OpenGL version	4.5

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	10 W
Speakers manufacturer	Waves
Built-in microphone	Yes
Audio chip	Realtek ALC3289-CG
Audio system	Waves MaxxAudio Pro

Camera

Specification	Value
Built-in camera	Yes
Total megapixels	2 MP
Camera HD type	Full HD
Camera resolution	1920 x 1080 pixels
Camera signal format	1080p
Privacy camera	Yes
Privacy type	Pop-up
Infrared (IR) camera	Yes

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	867 Mbit/s
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	4.2

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
Thunderbolt 3 ports quantity	0
Thunderbolt ports quantity	0
HDMI ports quantity	2
VGA (D-Sub) ports quantity	0
Headphone outputs	1
Microphone in	No
Combo headphone/mic port	Yes
DC-in jack	Yes
PowerShare	Yes
Number of USB ports with PowerShare support	1

Design

Specification	Value
Product colour	Black, Grey
Colour name	Era Gray
On/off button	Yes

Performance

Specification	Value
Product type	All-in-One PC
Motherboard chipset	Intel® H310

Software

Specification	Value
Operating system installed	Windows 10 Home
Operating system architecture	64-bit
Trial software	McAfee LiveSafe (30 days Trial), Microsoft Office (30 days Trial)

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	1.00
Intel Secure Key Technology version	1.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel Stable Image Platform Program (SIPP) version	0.00
Intel TSX-NI	No
Intel TSX-NI version	0.00
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® OS Guard	Yes
Intel® Optane™ Memory Ready	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	129940
Processor package size	37.5 x 37.5 mm
Scalability	1S
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes
Thermal solution specification	PCG 2015A

Power

Specification	Value
AC adapter power	130 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19.5 V

Multimedia

Specification	Value
Wide-angle lens camera	Yes

Pen

Specification	Value
Pen included	No

Weight & dimensions

Specification	Value
Width (with stand)	614 mm
Depth (with stand)	205.4 mm
Height (with stand)	454 mm
Weight (with stand)	10.7 kg
Width (without stand)	614 mm
Depth (without stand)	58 mm
Height (without stand)	389 mm
Weight (without stand)	8.07 kg

Recycling data

Specification	Value
Corrugated cardboard content per package	1.84 kg
Corrugated cardboard content per shipping (inner) case	1.73 kg
Corrugated cardboard content per box for accessories	107 g
High-density polyethylene (HDPE) content per package	688 g
Low-density polyethylene (LDPE) content per package	34 g

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m

Certificates

Specification	Value
EPEAT rating	71.8%

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Packaging content

Specification	Value
Mouse included on selected markets only	Yes
Keyboard included on selected markets only	Yes
Warranty card	Yes
AC adapter included	Yes
Power cord included	Yes
Manual	Yes

Logistics data

Specification	Value
Products per intermodal container (20ft)	150 pc(s)
Products per intermodal container (40ft, HC)	399 pc(s)
Pallet gross width	100 cm
Pallet gross length	120 cm
Pallet gross height	130.7 cm
Pallet gross weight	153.8 kg
Pallet volume weight	261.5 kg
Layers per pallet	2 pc(s)
Products per pallet layer	5 pc(s)
Products per pallet	10 pc(s)
Shipping (inner) case width	25.9 cm
Shipping (inner) case length	72.4 cm
Shipping (inner) case height	58.4 cm
Shipping (inner) case gross weight	14.6 kg
Shipping (inner) case volume weight	18.3 kg
Maximum number of stacking cartons	4 pc(s)

Other features

Specification	Value
AC adapter output current	6.7 A
Autonomy mode	No
Detachable display	No
Memory upgrade note	Additional memory sold separately
Stand type	Pedestal stand
Package material	Corrugated cardboard, High-Density Polyethylene (HDPE), Low-density polyethylene (LDPE)

Technical details

Specification	Value
Operating vibration	0.26 G
Non-operating vibration	1.37 G
Operating shock	40 G
Non-operating shock	105 G
