Inspiron 7790 Intel® Core™ i5 i5-10210U

68.6 cm (27") 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 1.25 TB HDD+SSD NVIDIA® GeForce® MX110 Windows 10 Ho

Model 7790Part no. CAI102BHLICF08OO3OJPEAN 5397184406434

214 specifications

Display68.6 cm (27")
Resolution1920 x 1080 pixels
ProcessorIntel® Core™ i5
Memory8 GB
Storage1.25 TB
GraphicsNVIDIA® GeForce® MX110

See all specifications

Overview

Display: 68.6 cm (27")
Resolution: 1920 x 1080 pixels
Processor: Intel® Core™ i5
Memory: 8 GB
Storage: 1.25 TB
Graphics: NVIDIA® GeForce® MX110

Brand: Dell
Category: All-in-One PCs/Workstations
Model: 7790
Part numbers: CAI102BHLICF08OO3OJP, CAI102SHLICF08ON3OJP, CAI102SHLICF08OO3OJP, CAI103BHLICS16ON3OJP, CAI103BHLICS16OO3OJP, CAI103SHLICS16ON3OJP +34 more
EAN / UPC: 5397184406434, 5397184472972, 5397184472989, 5397184286289 +10 more
Also known as: DELL Inspiron 7790 Intel® Core™ i5 i5-10210U 68.6 cm (27") 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 1.25 TB HDD+SSD NVIDIA® GeForce® MX110 Windows 10 Ho

Specifications

214 specifications in 24 groups

Display

Specification	Value
Display diagonal	68.6 cm (27")
Display resolution	1920 x 1080 pixels
Touchscreen	No
HD type	Full HD
LED backlight	Yes
Native aspect ratio	16:9
Display brightness	250 cd/m²
Panel type	IPS
Response time	25 ms
Pixel pitch	0.3114 x 0.3114 mm
Screen shape	Flat

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	10th gen Intel® Core™ i5
Processor model	i5-10210U
Processor cores	4
Processor threads	8
Processor boost frequency	4.2 GHz
Processor frequency	1.6 GHz
Processor cache	6 MB
Processor socket	BGA 1528
System bus rate	4 GT/s
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.1 GHz
Configurable TDP-up	25 W
Configurable TDP-down frequency	0.8 GHz
Configurable TDP-down	10 W
Maximum number of PCI Express lanes	16
PCI Express configurations	1x4, 2x2, 1x2+2x1, 4x1
PCI Express slots version	3.0
Processor codename	Comet Lake
Processor lithography	14 nm
Processor operating modes	64-bit
Tjunction	100 °C
Maximum internal memory supported by processor	64 GB
Memory types supported by processor	DDR4-SDRAM, LPDDR3-SDRAM
Memory clock speeds supported by processor	2666,2133 MHz
Memory bandwidth supported by processor (max)	41.66 GB/s

Memory

Specification	Value
Internal memory	8 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	2666 MHz
Memory layout (slots x size)	1 x 8 GB
Memory form factor	DIMM/SO-DIMM

Storage

Specification	Value
Total storage capacity	1.25 TB
Storage media	HDD+SSD
Number of storage drives installed	2
Total HDDs capacity	1 TB
Number of HDDs installed	1
HDD capacity	1 TB
HDD speed	5400 RPM
HDD size	2.5"
HDD interface	SATA
Total SSDs capacity	256 GB
Number of SSDs installed	1
SSD capacity	256 GB
NVMe	Yes
SSD interface	NVMe, PCI Express
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	NVIDIA® GeForce® MX110
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card	Yes
On-board graphics card model	Intel® UHD Graphics
Maximum on-board graphics card memory	32 GB
Number of displays supported (on-board graphics)	3
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
On-board graphics card DirectX version	12.0
On-board graphics card ID	0x9B41
On-board graphics card OpenGL version	4.5
Number of execution units	24

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	10 W
Audio chip	Realtek ALC3289-CG
Audio system	Waves MaxxAudio Pro

Camera

Specification	Value
Built-in camera	Yes
Total megapixels	2.07 MP
Camera HD type	Full HD
Camera resolution	1920 x 1080 pixels
Camera signal format	1080p
Privacy camera	Yes
Privacy type	Pop-up

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Antenna type	1x1
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
Thunderbolt ports quantity	0
HDMI input ports quantity	1
HDMI output ports quantity	1
HDMI ports quantity	2
Headphone outputs	0
Microphone in	No
Audio output	Yes
DC-in jack	Yes

Design

Specification	Value
Product colour	Silver
Colour name	Silver
Cable lock slot	Yes
On/off button	Yes

Performance

Specification	Value
Product type	All-in-One PC
Placement supported	Horizontal

Software

Specification	Value
Operating system installed	Windows 10 Home
Operating system architecture	64-bit
Operating system language	Multilingual
Bundled software	Financial Tracker & Retail Information

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Enhanced Intel SpeedStep Technology	Yes
Execute Disable Bit	Yes
Idle States	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Flex Memory Access	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel TSX-NI	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® My WiFi Technology (Intel® MWT)	Yes
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	195436
Processor package size	46 x 24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring Technologies	Yes

Power

Specification	Value
AC adapter power	130 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19.5 V

Pen

Specification	Value
Pen included	No

Weight & dimensions

Specification	Value
Width (with stand)	611.7 mm
Depth (with stand)	182 mm
Height (with stand)	453.2 mm
Weight (with stand)	7.35 kg
Width (without stand)	611.7 mm
Depth (without stand)	42 mm
Height (without stand)	395.4 mm
Weight (without stand)	6.71 kg
Package width	273 mm
Package depth	724 mm
Package height	584 mm
Package weight	10.9 kg

Recycling data

Specification	Value
Paper molded pulp content per package	0 g
Bamboo molded pulp content per package	0 g
Wheat straw molded pulp content per package	0 g
Grey board content per package	0 g
Corrugated cardboard content per package	2.1 kg
Corrugated cardboard content per shipping (inner) case	1.76 kg
Corrugated cardboard content per box for accessories	200 g
Corrugated cardboard content per sleeve for accessories	140 g
Polyethylene terephthalate (PET) content per package	0 g
High-density polyethylene (HDPE) content per package	0 g
Low-density polyethylene (LDPE) content per package	420 g
Polypropylene (PP) content per package	60 g
Polystyrene (PS) content per package	0 g
Other materials content per package	30 g

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m

Certificates

Specification	Value
EPEAT rating	80.46%

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Packaging content

Specification	Value
Mouse included on selected markets only	Yes
Keyboard included on selected markets only	Yes
AC adapter included	Yes
Manual	Yes

Logistics data

Specification	Value
Products per intermodal container (20ft)	100 pc(s)
Products per intermodal container (40ft)	210 pc(s)
Pallet gross width	100 cm
Pallet gross length	120 cm
Pallet gross weight	62.5 kg
Pallet volume weight	144.8 kg
Layers per pallet	1 pc(s)
Products per pallet layer	5 pc(s)
Products per pallet	5 pc(s)
Package volume weight	19.238128 kg
Maximum number of stacking cartons	3 pc(s)

Other features

Specification	Value
3D	No
AC adapter output current	6.7 A
Autonomy mode	No
Detachable display	No
Stand type	Vessel stand
Package material	Corrugated cardboard, Low-density polyethylene (LDPE), Polypropylene (PP)

Technical details

Specification	Value
Operating vibration	0.26 G
Non-operating vibration	1.37 G
Operating shock	40 G
Non-operating shock	105 G
