Shuttle X50V2 Plus

Model X50V2 PlusPart no. PAB-X50V2P31EAN 5711045293788

89 specifications

Display39.6 cm (15.6")
Resolution1366 x 768 pixels
ProcessorIntel Atom®
Memory0 GB
OSNo
ColourBlack

See all specifications

Overview

Display: 39.6 cm (15.6")
Resolution: 1366 x 768 pixels
Processor: Intel Atom®
Memory: 0 GB
OS: No
Colour: Black

Brand: Shuttle
Category: All-in-One PCs/Workstations
Model: X50V2 Plus
Part numbers: PAB-X50V2P31, X50V2PLUS, X50V2 PLUS WHITE, X50V2 PLUS BLACK
EAN / UPC: 5711045293788, 811686003434, 811686004219, 5053973544984 +5 more
Also known as: Shuttle X50V2 Plus Intel Atom® D525 39.6 cm (15.6") 1366 x 768 pixels Touchscreen 0 GB Black

Specifications

89 specifications in 18 groups

Display

Specification	Value
Display diagonal	39.6 cm (15.6")
Display resolution	1366 x 768 pixels
Touchscreen	Yes
Native aspect ratio	16:9

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	D525
Processor cores	2
Processor threads	4
Processor frequency	1.8 GHz
Processor cache	1 MB
Processor cache type	L2
L2 cache	1 MB
Processor socket	BGA 559
Thermal Design Power (TDP)	13 W
Bus type	DMI
Number of Processing Die Transistors	176 M
Processing Die size	87 mm²
Processor code	SLBXC
Processor codename	Pineview
Processor lithography	45 nm
Processor operating modes	64-bit
Stepping	B0
Tjunction	100 °C
Conflict-Free processor	No
Maximum internal memory supported by processor	4 GB
Memory bandwidth supported by processor (max)	6.4 GB/s
Memory channels supported by processor	Single
ECC supported by processor	No

Memory

Specification	Value
Internal memory	0 GB
Maximum internal memory	4 GB
Memory slots type	SO-DIMM

Storage

Specification	Value
Number of storage drives supported	1
HDD size	2.5"
Card reader integrated	Yes
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD

Audio

Specification	Value
Audio system	IDT92HD81

Camera

Specification	Value
Built-in camera	Yes

Network

Specification	Value
Wi-Fi	Yes
Ethernet LAN	Yes

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	4
VGA (D-Sub) ports quantity	1
Headphone outputs	1
Microphone in	Yes

Design

Specification	Value
Product colour	Black
Panel mounting interface	100 x 100 mm

Performance

Specification	Value
Motherboard chipset	Intel NM10

Software

Specification	Value
Operating system installed	No

Processor special features

Specification	Value
Embedded options available	Yes
Enhanced Intel SpeedStep Technology	No
Execute Disable Bit	Yes
Idle States	No
Intel 64	Yes
Intel Demand Based Switching	No
Intel Enhanced Halt State	No
Intel Trusted Execution Technology	No
Intel Virtualization Technology (VT-x)	No
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	No
Physical Address Extension (PAE)	32 bit
Processor ARK ID	49490
Processor package size	22 x 22 mm
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Monitoring Technologies	No

Weight & dimensions

Specification	Value
Weight (with stand)	3.6 kg

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	0 - 60%

Certificates

Specification	Value
Certification	CE, FCC, BSMI, R&TT, RoHS

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Packaging content

Specification	Value
Quick start guide	Yes

Other features

Specification	Value
Graphics card family	Intel
Chassis type	All-in-One
Compatible operating systems	Windows XP, Windows Vista, Windows 7
Compatible processor series	Intel Atom®
Copper ethernet cabling technology	100BASE-TX, 100BASE-T
Dimensions (WxDxH)	391.3 x 36 x 327 mm
Display	LCD
Graphics card	GMA 3150
Maximum graphics card memory	256 MB
Megapixel (approx.)	2 MP
Networking features	Fast Ethernet, WLAN
Number of processors installed	1
Power requirements	100-240V AC, 50/60Hz
Power supply	40 W
Safety	TÜV, CB, BSMI
Storage drive interface	Serial ATA
