APPC-10SLBN (R23-7581)
Model APPC-10SLBN-R23Part no. 5010505
81 specifications
- Display25.6 cm (10.1")
- Resolution1280 x 800 pixels
- ProcessorRockchip
- Memory4 GB
- Storage16 GB
- GraphicsNot available
Overview
- Display
- 25.6 cm (10.1")
- Resolution
- 1280 x 800 pixels
- Processor
- Rockchip
- Memory
- 4 GB
- Storage
- 16 GB
- Graphics
- Not available
- Brand
- ProDVX
- Category
- All-in-One PCs/Workstations
- Model
- APPC-10SLBN-R23
- Part number
- 5010505
- Also known as
- ProDVX APPC-10SLBN (R23-7581)
Specifications
81 specifications in 18 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 25.6 cm (10.1") |
| Display resolution | 1280 x 800 pixels |
| Touchscreen | Yes |
| HD type | HD |
| LED backlight | Yes |
| Touch technology | Multi-touch |
| Native aspect ratio | 16:10 |
| Display brightness | 500 cd/m² |
| Display surface | Matt |
| Panel type | IPS |
| Anti-glare screen | Yes |
| Contrast ratio (typical) | 800:1 |
| Multi-touch | Yes |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 160° |
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Rockchip |
| Processor family | Rockchip |
| Processor model | RK3568 |
| Processor cores | 4 |
| Processor frequency | 2 GHz |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR4-SDRAM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 16 GB |
| Storage media | eMMC |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | ARM |
| On-board graphics card | Yes |
| On-board graphics card family | ARM Mali |
| On-board graphics card model | Arm Mali-G52 |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 4 W |
| Built-in microphone | Yes |
| Audio formats supported | AAC, ASF, MP2, OGG, WAV, WMA |
Camera
| Specification | Value |
|---|---|
| Built-in camera | No |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n), 802.11a |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000,100,10 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 1 |
| HDMI output ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Audio output | Yes |
| DC-in jack | Yes |
| Micro-USB ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | ABS synthetics |
| Panel mounting interface | 75 x 75 mm |
| VESA mounting | Yes |
| Wall mountable | Yes |
Performance
| Specification | Value |
|---|---|
| Product type | All-in-One tablet PC |
Software
| Specification | Value |
|---|---|
| Operating system installed | Android 12 |
Power
| Specification | Value |
|---|---|
| AC adapter output voltage | 12 V |
| Power consumption (typical) | 23 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (without stand) | 255.3 mm |
| Depth (without stand) | 26.7 mm |
| Height (without stand) | 181 mm |
| Weight (without stand) | 650 g |
| Weight | 650 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC), CE, RoHS, REACH, UKCA |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | No |
| Cables included | No |
Other features
| Specification | Value |
|---|---|
| AC adapter output current | 2 A |
| Mean time between failures (MTBF) | 50000 h |
| Video formats supported | H.264, MP4, MPEG2, MPEG4, MPG |
| Backlight | Yes |
| Backlight type | Edge LED |
| Battery type | CR1220 Lithium metal, non rechargeable |
| Near Field Communication (NFC) | Yes |
