Nilox W10PRO Intel® Core™ i3 i3-8100
Nilox

W10PRO Intel® Core™ i3 i3-8100

60.5 cm (23.8") 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 240 GB SSD Windows 10 Pro Wi-Fi 5 (802.11ac) White

Model W10PROPart no. NX24AIOWPI3NEROEAN 8051122175727

108 specifications
  • Display60.5 cm (23.8")
  • Resolution1920 x 1080 pixels
  • ProcessorIntel® Core™ i3
  • Memory8 GB
  • Storage240 GB
  • SpeedWi-Fi 5 (802.11ac)
See all specifications

Overview

Display
60.5 cm (23.8")
Resolution
1920 x 1080 pixels
Processor
Intel® Core™ i3
Memory
8 GB
Storage
240 GB
Speed
Wi-Fi 5 (802.11ac)
Brand
Nilox
Model
W10PRO
Part number
NX24AIOWPI3NERO
EAN / UPC
8051122175727
Also known as
Nilox W10PRO Intel® Core™ i3 i3-8100 60.5 cm (23.8") 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 240 GB SSD Windows 10 Pro Wi-Fi 5 (802.11ac) White

Specifications

108 specifications in 16 groups

Display

Display diagonal60.5 cm (23.8")
Display resolution1920 x 1080 pixels
TouchscreenNo
Native aspect ratio16:9
Display brightness300 cd/m²

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i3
Processor generation8th gen Intel® Core™ i3
Processor modeli3-8100
Processor cores4
Processor threads4
Processor frequency3.6 GHz
Processor cache6 MB
Processor cache typeSmart Cache
Processor socketLGA 1151 (Socket H4)
System bus rate8 GT/s
Thermal Design Power (TDP)65 W
Bus typeDMI3
Maximum number of PCI Express lanes16
PCI Express configurations1x16, 1x8+2x4, 2x8
PCI Express slots version3.0
Processor codenameCoffee Lake
Processor lithography14 nm
Processor operating modes64-bit
Tjunction100 °C
Conflict-Free processorYes
Maximum internal memory supported by processor64 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2400 MHz
Memory bandwidth supported by processor (max)37.5 GB/s

Memory

Internal memory8 GB
Internal memory typeDDR4-SDRAM
Maximum internal memory32 GB
Memory slots typeSO-DIMM
Memory clock speed2400 MHz

Storage

Total storage capacity240 GB
Storage mediaSSD
Total SSDs capacity240 GB
Number of SSDs installed1
SSD capacity240 GB
SSD interfaceSATA III
Optical drive typeNo
Card reader integratedYes

Graphics

On-board GPU manufacturerIntel
On-board graphics cardYes
On-board graphics card modelIntel® UHD Graphics 630
Maximum on-board graphics card memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1100 MHz
On-board graphics card DirectX version12.0
On-board graphics card ID0x3E91
On-board graphics card OpenGL version4.5
Number of execution units23

Audio

Built-in speaker(s)Yes

Camera

Built-in cameraYes

Network

Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standardsWi-Fi 5 (802.11ac)
BluetoothYes

Ports & interfaces

USB 2.0 ports quantity4
HDMI ports quantity1
VGA (D-Sub) ports quantity1

Design

Product colourWhite

Performance

Product typeAll-in-One PC

Software

Operating system installedWindows 10 Pro
Operating system architecture64-bit

Processor special features

CPU configuration (max)1
Embedded options availableYes
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Enhanced Halt StateYes
Intel Identity Protection Technology version1.00
Intel Secure Key Technology version1.00
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)No
Intel Stable Image Platform Program (SIPP) version0.00
Intel TSX-NINo
Intel TSX-NI version0.00
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)No
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® InTru™ 3D TechnologyYes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Turbo Boost TechnologyNo
Processor ARK ID126688
Processor package size37.5 x 37.5 mm
Scalability1S
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring TechnologiesYes
Thermal solution specificationPCG 2015C

Power

AC adapter power90 W

Weight & dimensions

Width (with stand)540 mm
Depth (with stand)143 mm
Height (with stand)410 mm
Weight (with stand)4 kg

Other features

Power supply90 W
