Inspiron 3480 Intel® Core™ i5 i5-8265U
Dell

Inspiron 3480 Intel® Core™ i5 i5-8265U

60.5 cm (23.8") 1920 x 1080 pixels Touchscreen All-in-One PC 8 GB DDR4-SDRAM 1 TB HDD Windows 10 Home Wi-Fi 5 (802.1

Model 3480Part no. PCD02EAN 884116314752

184 specifications
  • Display60.5 cm (23.8")
  • Resolution1920 x 1080 pixels
  • ProcessorIntel® Core™ i5
  • Memory8 GB
  • Storage1 TB
  • GraphicsNot available
See all specifications

Overview

Display
60.5 cm (23.8")
Resolution
1920 x 1080 pixels
Processor
Intel® Core™ i5
Memory
8 GB
Storage
1 TB
Graphics
Not available
Brand
Dell
Model
3480
Part numbers
PCD02, HVXJK, I3480-7752BLK-PUS, SMI3480W10S4235T, SMI3480W10S7083T, SMI3480W10S5173T +30 more
EAN / UPC
884116314752, 884116314431, 884116338130, 884116338109 +2 more
Also known as
DELL Inspiron 3480 Intel® Core™ i5 i5-8265U 60.5 cm (23.8") 1920 x 1080 pixels Touchscreen All-in-One PC 8 GB DDR4-SDRAM 1 TB HDD Windows 10 Home Wi-Fi 5 (802.1

Specifications

184 specifications in 20 groups

Display

Display diagonal60.5 cm (23.8")
Display resolution1920 x 1080 pixels
TouchscreenYes
HD typeFull HD
LED backlightYes
Touch technologyMulti-touch
Native aspect ratio16:9
Display brightness250 cd/m²
Panel typeIPS
Response time25 ms
Pixel pitch0.25 x 0.25 mm
Screen shapeFlat

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i5
Processor generation8th gen Intel® Core™ i5
Processor modeli5-8265U
Processor cores4
Processor threads8
Processor boost frequency3.9 GHz
Processor frequency1.6 GHz
Processor cache6 MB
Processor cache typeSmart Cache
Processor socketBGA 1528
System bus rate4 GT/s
Thermal Design Power (TDP)15 W
Configurable TDP-up frequency1.8 GHz
Configurable TDP-up25 W
Configurable TDP-down frequency0.8 GHz
Configurable TDP-down10 W
Bus typeOPI
Maximum number of PCI Express lanes16
PCI Express configurations1x4, 2x2
PCI Express slots version3.0
Processor codenameWhiskey Lake
Processor lithography14 nm
Processor operating modes64-bit
Tjunction100 °C
Maximum internal memory supported by processor32 GB
Memory types supported by processorDDR4-SDRAM, LPDDR3-SDRAM
Memory clock speeds supported by processor2133 MHz
Memory bandwidth supported by processor (max)37.5 GB/s
Memory channels supported by processorDual
ECC supported by processorNo

Memory

Internal memory8 GB
Internal memory typeDDR4-SDRAM
Maximum internal memory16 GB
Memory slots2
Memory slots typeSO-DIMM
Memory clock speed2400 MHz
Memory layout (slots x size)1 x 8 GB
Memory form factorDIMM/SO-DIMM

Storage

Total storage capacity1 TB
Storage mediaHDD
Number of storage drives installed1
Total HDDs capacity1 TB
Number of HDDs installed1
HDD capacity1 TB
HDD speed5400 RPM
HDD size2.5"
HDD interfaceSATA
Optical drive typeNo
Card reader integratedYes
Compatible memory cardsSD, SDHC, SDXC

Graphics

Discrete graphics cardNo
Discrete graphics card modelNot available
On-board graphics cardYes
On-board graphics card familyIntel® UHD Graphics
On-board graphics card modelIntel® UHD Graphics
Maximum on-board graphics card memory32 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency300 MHz
On-board graphics card dynamic frequency (max)1100 MHz
On-board graphics card DirectX version12.0
On-board graphics card ID0x3EA0
On-board graphics card OpenGL version4.5

Audio

Built-in speaker(s)Yes
Audio chipRealtek ALC3246
Audio systemHD

Camera

Built-in cameraYes
Total megapixels0.92 MP
Camera HD typeHD
Camera resolution1280 x 720 pixels
Camera signal format720p

Network

Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
BluetoothYes
Bluetooth version5.0

Ports & interfaces

Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
Thunderbolt 3 ports quantity0
Thunderbolt ports quantity0
HDMI ports quantity1
HDMI version1.4
Headphone outputs0
Microphone inNo
Combo headphone/mic portYes
DC-in jackYes
PowerShareYes
Number of USB ports with PowerShare support1

Design

Product colourBlack
On/off buttonYes

Performance

Product typeAll-in-One PC
BIOS passwordYes
HDD user passwordYes
Placement supportedHorizontal

Software

Operating system installedWindows 10 Home
Operating system architecture64-bit

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Enhanced Halt StateYes
Intel Flex Memory AccessYes
Intel Identity Protection Technology version1.00
Intel Secure Key Technology version1.00
Intel Smart Response Technology version1.00
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)No
Intel Stable Image Platform Program (SIPP) version0.00
Intel TSX-NINo
Intel TSX-NI version0.00
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® My WiFi Technology (Intel® MWT)Yes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Smart Response TechnologyYes
Intel® Turbo Boost Technology2.0
Processor ARK ID149088
Processor package size46x24 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring TechnologiesYes

Power

AC adapter power90 W
AC adapter frequency50/60 Hz
AC adapter input voltage100 - 240 V
AC adapter output voltage19.5 V

Pen

Pen includedNo

Weight & dimensions

Width (with stand)548.8 mm
Depth (with stand)219.2 mm
Height (with stand)414.9 mm
Weight (with stand)5.85 kg
Width (without stand)548.8 mm
Depth (without stand)43.5 mm
Height (without stand)358 mm

Operational conditions

Operating temperature (T-T)10 - 35 °C
Storage temperature (T-T)-40 - 65 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)5 - 95%
Operating altitude0 - 3048 m
Non-operating altitude0 - 10668 m

Packaging content

Mouse includedYes
Mouse included on selected markets onlyYes
Keyboard includedYes
Keyboard included on selected markets onlyYes
AC adapter includedYes
Drivers includedYes
Power cord includedYes
ManualYes

Other features

3DNo
Autonomy modeNo
Detachable displayNo
Memory upgrade noteAdditional memory sold separately

Technical details

Operating vibration0.26 G
Non-operating vibration1.307 G
Operating shock40 G
Non-operating shock105 G
